Beckhoff – CX1030-0123 CPU module, DVI/USB, Microsoft Windows Embedded Standard 2009, TwinCAT 2 NC I runtime

MPN: CX1030-0123 · Brand: Beckhoff

Price on request

Discontinued by Beckhoff — we can still source the original CX1030-0123 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	IPC service products (discontinued)
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the CX1030-0123 now that it is discontinued?

Yes. Beckhoff has discontinued the CX1030-0123, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can CX1030-0123 be shipped?

CX1030-0123 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CX1030-0123 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CX1030-0123 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CX1030-0123, subject to availability and destination.

The CX1030 basic CPU module offers Intel® Pentium® M power on the DIN rail. The CX1030 has a 1.8 GHz Intel® Pentium® M CPU. The CPU is cooled via the cooling module and an easily exchangeable fan cartridge located on the underside of the housing. The fan

Beckhoff CX1030-0123 — CPU module, DVI/USB, Microsoft Windows Embedded Standard 2009, TwinCAT 2 NC I runtime. Beckhoff service-phase product: no longer in the current range. PartnerPLC sources discontinued and surplus Beckhoff automation parts — request a quote for price, condition and lead time.

Specifications

Technical data

Product family	CX1030 – Basic CPU module
Lifecycle	Service phase (discontinued, no longer in Beckhoff's product range)
Processor	Intel ® Pentium ® M, 1.8 GHz clock frequency
Number of cores	1
Flash memory	slot for CompactFlash ® card, 128 MB included (expandable), expansion slot: 1 x CompactFlash ® type I+II insert with eject mechanism
Main memory	256 MB DDR RAM (expandable ex factory to 1 GB)
Interfaces	2 x RJ45 10/100 Mbit/s (internal switch)
Cooling	cooling module + fan cartridge featuring speed control with double ball bearing fans, easily replaceable
Diagnostics LED	1 x power, 2 x LAN link/activity, TC status, 1 x flash access
Clock	internal battery-backed clock for time and date (battery exchangeable)
Operating system	Windows Embedded CE 6, Windows Embedded Standard 2009
Control software	TwinCAT 2 PLC runtime, NC PTP runtime, NC I runtime
System bus	16 bit ISA (PC/104)
I/O connection	via power supply module (E-bus, K-bus, K-bus/IP-Link)
Power supply	via system bus (through CX1100-0012 [K-bus], CX1100-0013 [K-bus, IP-Link], CX1100-014 [E-bus] power supply module)
Max. power consumption	32 W
Max. power consumption E-bus/K-bus	10 W (5 V/max. 2 A)
Weight	approx. 580 g
Dimensions (W x H x D)	96 mm x 112 mm x 99 mm
Relative humidity	95%, no condensation
Operating temperature	0…50°C
Storage temperature	-25…+85°C
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protection rating	IP20
Approvals/markings	CE, UL
