Beckhoff AM8853-wFyz

Stainless steel servomotors from 6.40 Nm (M0)

MPN
AM8853-wFyz
Category
AM8853
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Beckhoff parts? We buy surplus →

What is the Beckhoff AM8853-wFyz?

The AM8853 stainless steel servomotor is suitable for use in the food, chemical and pharmaceutical industries in the 100…480 V AC voltage range. The standstill torque of the motor is 6.40 Nm. It is available with the OCT feedback system (absolute

Specifications

Specifications

Motor typepermanent magnet-excited three-phase synchronous motor
Nominal voltage100…480 V AC
Standstill torque6.40 Nm
Rated torque4.30 Nm
Peak torque52.50 Nm
Rated speed2000 min-1
Rated power0.90 kW
Standstill current2.80 A
Peak current26.9 A
Torque constant2.28 Nm/A
Rotor moment of inertia5.970 kgcm²
Motor feedbackresolver, single-turn absolute encoder OCT, 18 bit, single-turn or multi-turn absolute encoder, electronic nameplate OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate, B/SSD
Coolingconvection
Connection technologyM23 speedtec® socket or direct connection for AX5000/AX8000
Ambient temperature (operation)5…40°C
Approvals/markingsCE, cURus
Protection ratingIP69K
Design formflange-mounted according to IM B5, IM V1, IM V3
Materialstainless steel
Coating/surfacestainless steel
a95 j6
b24 k6
d50 mm
l115 mm
r134 mm
k (without brake)212 mm
k (with brake)258 mm

AM8853-wFyz: frequently asked questions

When can AM8853-wFyz be shipped?

AM8853-wFyz is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up AM8853-wFyz in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for AM8853-wFyz and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for AM8853-wFyz, subject to availability and destination.
