Balluff – BES018F BES 516-300-S254-S49 – Inductive proximity switches and proximity sensors

MPN: BES018F · Brand: Balluff

Price on request

Discontinued by Balluff — we can still source the original BES018F (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Inductive proximity switches and proximity sensors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Recommended replacement	BES01T3
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the BES018F now that it is discontinued?

Yes. Balluff has discontinued the BES018F, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Balluff names the BES01T3 as its successor — we can quote both.

When can BES018F be shipped?

BES018F is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BES018F in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BES018F and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BES018F, subject to availability and destination.

Balluff BES018F (BES 516-300-S254-S49) — Inductive proximity switches and proximity sensor. Dimension: 59 x 8 x 8 mm; Style Housing: 8x8; Installation: for flush mounting; Range: 1.5 mm; Switching output: NPN normally open (NO). Discontinued by Balluff; Balluff names BES01T3 as alternative. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued by Balluff
Type designation	BES 516-300-S254-S49
Product group	Inductive proximity switches and proximity sensors
Balluff alternatives	BES01T3

Key features

Dimension	59 x 8 x 8 mm
Style Housing	8x8
Installation	for flush mounting
Range	1.5 mm
Switching output	NPN normally open (NO)
Switching frequency	5000 Hz
Housing material	Zinc, Die casting
Material sensing surface	PBT
Connection	Connector, M8x1-Male, 3-pin
Operating voltage Ub	10...30 VDC
Ambient temperature	-25...70 °C
IP rating	IP67
Approval/Conformity	CE cULus EAC WEEE
Principle of operation	Inductive sensor
