Allen-Bradley – 1783-WAPBK9 Stratix 5100 Wireless AP-WGB (RegD B)

MPN: 1783-WAPBK9 · Brand: Rockwell Automation / Allen-Bradley

Price on request

Discontinued by Rockwell Automation / Allen-Bradley — we can still source the original 1783-WAPBK9 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Stratix 2100 Unmanaged Industrial Ethernet Switch
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the 1783-WAPBK9 now that it is discontinued?

Yes. Rockwell Automation / Allen-Bradley has discontinued the 1783-WAPBK9, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 1783-WAPBK9 be shipped?

1783-WAPBK9 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1783-WAPBK9 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1783-WAPBK9 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1783-WAPBK9, subject to availability and destination.

Allen-Bradley 1783-WAPBK9 — Stratix 5100 Wireless AP-WGB (RegD B). Discontinued by Rockwell Automation on December 07, 2018. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued
Discontinued date	December 07, 2018
Replacement category (Rockwell)	No planned RA replacement
Repair options available	Yes

Specifications

Bridge function	true
Built-in	false
Ceiling mounting	true
Connection for external antenna	true
Degree of protection (IP)	IP30
Depth	22.04 cm
Encoding	WPA2
Ethernet	true
Flush-mounted installation	true
For use in	United States
Frequency band	2.4 GHz and 5 GHz
Height	4.67 cm
Humidity, non-condensing	10 %
Includes	Mounting bracket, screws, power adapter, (4) Wi-Fi antennas, console cable
Input voltage at 50/60 Hz	100 V
Integrated firewall	false
Managed	false
Max. data transmission rate	450 mbit/s
Number of ports 10/100/1000 Mbps LAN	1
Operating temperature	-20 °C
Output current, DC	380 mA
Output voltage, DC	48 V
Pole fastening	false
Power dissipation	12.95 W
Power over Ethernet	true
Pulse (digital) output	12.95 W
Radio protocol	IEEE 802.11 b/g/n
Regulatory domain, B FCC	2.412 - 2.462 GHz 11 channels, 5.180 - 5.320 GHz 8 channels, 5.500 - 5.700 GHz 12 channels, 5.745 - 5.825 GHz 5 channels
Repeater function	true
Socket outlet adapter	false
Storage temperature	-30 °C
Suitable for DIN rail (top hat rail) mounting	false
VPN-security	false
Wall mounting	true
Weight	1.22 kg
Width	22.04 cm
