Home / ABB / Flameproof IEC Low voltage motors / ABB M3JM 400LA 4

ABB

ABB M3JM 400LA 4

MPN: M3JM 400LA 4
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB M3JM 400LA 4?

M3JM 400LA 4

Specifications

Ordering

ABB Type Designation	M3JM 400LA 4
Invoice Description	M3JM 400LA 4
Product Name	3-Phase squirrel cage motor
Product Type	3JM2__M3JM_IE2_Group_I_Flameproof_Exd_mining_motor
Country or Territory of Origin	Finland
Customs Tariff Number	85015394
Medium Description	?kW, 4P, Frame Size 400, 3 Phases, 400V, ?Hz, IP66 Enclosure, IMB5/IM3001 Mounting (3GJM402510-BDG) kW
Short Description	?kW, 4P, Frame Size 400, 3PH, 400V, ?Hz, IP66, IMB5/IM3001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE2, Full Load (100%) 95.1 %, Partial Load (75%) 94.9 %, Partial Load (50%) 94.0 %
IP Class	IP66
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	4
Two Speed Motor	No
Type of Duty	S1
Voltage Code	D
EX-Protection	Exdb

Mechanical

Frame Material	Cast Iron
Frame Size	400
Bearing	6324/C3
Bearing NDE	6319/C3
IM Class	IMB5 IM3001
Terminator Box Location	Top

Dimensions

Product Net Weight	3234 kg kg
Gross Weight	3274 kg kg

Environmental

WEEE Category

4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100

M3JM 400LA 4: frequently asked questions

When can M3JM 400LA 4 be shipped?

M3JM 400LA 4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up M3JM 400LA 4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for M3JM 400LA 4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for M3JM 400LA 4, subject to availability and destination.
