ABB

ABB 3GVA081330-ASS

M2VAM 80MC 2

MPN: 3GVA081330-ASS
Category: Flameproof IEC Low voltage motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB 3GVA081330-ASS?

M2VAM 80MC 2

Specifications

Ordering

ABB Type Designation	M2VAM 80MC 2
Invoice Description	M2VAM 80MC 2
Product Name	3-Phase squirrel cage motor
Product Type	MVA3__M2VAM_IE3_AA
Country or Territory of Origin	China
Customs Tariff Number	85015220
Medium Description	?kW, 2P, Frame Size 80, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GVA081330-ASS) kW
Short Description	?kW, 2P, Frame Size 80, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default	--
Altitude	1000 m m
Ambient Temperature	50 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE3, Full Load (100%) 82.7 %, Partial Load (75%) 82.4 %, Partial Load (50%) 79.6 %
IE Class Data (60 Hz)	IE Class IE3, Full Load (100%) 84.0 %, Partial Load (75%) 83.3 %, Partial Load (50%) 80.4 %
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S

Mechanical

Frame Material	Aluminum
Frame Size	80
Bearing	6204-2Z/C3
Bearing NDE	6203-2Z/C3
IM Class	IMB3 IM1001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	12 kg kg
Gross Weight	15 kg kg

Environmental

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC

26101100
