What is the ABB 3GVA081002BSPTC?

No Description Available

Specifications

Ordering

ABB Type Designation	M2VA 80 B-2
Product Name	3-Phase squirrel cage motor
Product Type	M2VA
Country or Territory of Origin	Italy
Customs Tariff Number	85015220

Electrical

Temperature Class Default	--
Output Power	1.10 kW kW
Altitude	1000 m m
Ambient Temperature	40 °C
IC Class	IC411
IE Class Data (50 Hz)	IE Class IE1
IP Class	IP55
Insulation Class	ICLF
Direction of Rotation	Both sides
Number of Poles (High)	2
Two Speed Motor	No
Type of Duty	S1
Voltage Code	S

Mechanical

Frame Size	80
Bearing	6204-2ZC3
Bearing NDE	6203-2ZC3
Lubrication	For life
IM Class	IMB5 IM3001
Terminator Box Location	D-End top

Dimensions

Product Net Weight	11 kg kg
Gross Weight	11.2 kg kg

External Classifications and Standards

Standards	IEC 60034-1
UNSPSC	26101100
