ABB 3GJP161440-BEH
M3JP 160MLD 2
- MPN
- 3GJP161440-BEH
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the ABB 3GJP161440-BEH?
(3GJP161440-BEH)
Specifications
Ordering
| ABB Type Designation | M3JP 160MLD 2 |
| Invoice Description | HIGH OUTPUT |
| Product Name | 3-Phase squirrel cage motor |
| Product Type | 3JP2__M3JP_IE2_Flameproof_Exd_motor |
| Country or Territory of Origin | Finland |
| Customs Tariff Number | 85015230 |
| Replaced Product ID (OLD) | 3GJP161440-BEG |
Electrical
| Temperature Class Default | T4 |
| Altitude | 1000 m m |
| Ambient Temperature | 40 °C |
| IC Class | IC411 |
| IP Class | IP55 |
| Insulation Class | ICLF |
| Number of Poles (High) | 2 |
| Two Speed Motor | No |
| Type of Duty | S1 |
| Voltage Code | E |
| EX-Protection | Exdb |
| Gas Group | IIB |
Mechanical
| Frame Material | Cast Iron |
| Frame Size | 160 |
| Bearing | 6309/C3 |
| Bearing NDE | 6309/C3 |
| IM Class | IMB5 IM3001 |
Dimensions
| Product Net Weight | 239 kg kg |
| Gross Weight | 249 kg kg |
Environmental
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) cm |
| SCIP | 297e96db-dbee-43c1-ad2d-ddd583080bb8 Finland |
External Classifications and Standards
| UNSPSC | 26101100 |
