ABB 3GAR112452-ESE
M3ARS 112MB 4 HO
- MPN
- 3GAR112452-ESE
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the ABB 3GAR112452-ESE?
Alum.AC brake motor
Specifications
Ordering
| ABB Type Designation | M3ARS 112MB 4 HO |
| Invoice Description | Alum.AC brake motor |
| Product Name | 3-Phase squirrel cage motor |
| Product Type | AR___Aluminium_Brake_Motor |
| Country or Territory of Origin | Spain, Poland |
| Customs Tariff Number | 85015220 |
Electrical
| Temperature Class Default | -- |
| Altitude | 1000 m m |
| Ambient Temperature | 40 °C |
| IC Class | IC411 |
| IP Class | IP55 |
| Insulation Class | ICLF |
| Direction of Rotation | Both sides |
| Number of Poles (High) | 4 |
| Two Speed Motor | No |
| Type of Duty | S1 |
| Voltage Code | S |
Mechanical
| Frame Material | Aluminum |
| Frame Size | 112 |
| Bearing | 6206-2Z/C3 |
| Bearing NDE | 6206-2Z/C3 |
| Lubrication | For life |
| IM Class | IMB5 IM3001 |
| Terminator Box Location | D-End top |
Dimensions
| Product Net Weight | 40 kg kg |
| Gross Weight | 40.67 kg kg |
External Classifications and Standards
| Standards | IEC 60034-1 |
| UNSPSC | 26101100 |
3GAR112452-ESE: frequently asked questions
When can 3GAR112452-ESE be shipped?
3GAR112452-ESE is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3GAR112452-ESE in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3GAR112452-ESE and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GAR112452-ESE, subject to availability and destination.
