ABB 3BDH000509R1 – CM 100-P, Coax-Module

MPN: 3BDH000509R1 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Symphony Plus
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.17 kg

Shipping & availability

When can 3BDH000509R1 be shipped?

3BDH000509R1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3BDH000509R1 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3BDH000509R1 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3BDH000509R1, subject to availability and destination.

Electrical line with 75 Ohm coaxial cable, point-to-point

or Y-branching

ABB 3BDH000509R1 — CM 100-P, Coax-Module (Symphony Plus). PartnerPLC sources discontinued and surplus ABB automation parts — request a quote for price, condition and lead time.

Specifications

Product ID	3BDH000509R1
ABB type designation	CM 100-P
System	Symphony Plus
Product group	S+ MR > S+ MR - Communication Modules
HS Code	851762 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Teleph
RoHS Information	Following EU Directive 2011/65/EU
Number of Batteries	0
Width	180 mm
Height	217 mm
Depth / Length	67 mm
Weight	0.17 kg
