ABB 1SFN035701R1000 – VM750V Mechanical Interlock Unit
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ABB Block Contactors |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.2 kg |
| UPC / EAN | 7320500222126 |
Shipping & availability
When can 1SFN035701R1000 be shipped?
1SFN035701R1000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1SFN035701R1000 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1SFN035701R1000 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SFN035701R1000, subject to availability and destination.
Interlock unit for mechanical interlocking of two vertical mounted a.c. or d.c. operated contactors of same or different rating according to cataog table
Specifications
General
| Order code (ABB product ID) | 1SFN035701R1000 |
| Type | VM750V |
| Lifecycle | Active (current ABB product) |
Ordering
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
Dimensions
| Product Net Width | 15 mm |
| Product Net Depth / Length | 70 mm |
| Product Net Height | 123.5 mm |
| Product Net Weight | 0.2 kg |
Technical
| Terminal Type | Screw Terminals |
| Suitable For | AF400, AF460, AF580, AF750, AF1250 |
| Suitable for Product Class | Block Contactors |
| Product Name | Mechanical Interlock Unit |
Material Compliance
| WEEE B2C / B2B | Business To Business |
| WEEE Category | Product Not in WEEE Scope |
External Classifications and Standards
| Object Classification Code | R |
| ETIM 7 | EC001044 - Mechanic interlock for switch |
| ETIM 8 | EC001044 - Mechanic interlock for switch |
| ETIM 9 | EC001044 - Mechanic interlock for switch |
| eClass | V11.0 : 27371303 |
| UNSPSC | 39121529 |
| E-Number (Norway) | 4116140 |
| E-Number (Sweden) | 4116140 |
Downloads & documentation
Official documents from ABB, downloaded directly from the manufacturer.
Data sheets & manuals
| Data Sheet, Technical Information (1SBC100214C0202) | |
| Instructions and Manuals (1SFC380036-89) |
CAD & dimension drawings
| CAD Dimensional Drawing (2CDC001079B0201) |
