ABB 1SFL637025R6811

GAF750-10-11 24-60V DC Contactor

MPN
1SFL637025R6811
EAN
7320500400838
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare ABB parts? We buy surplus →

What is the ABB 1SFL637025R6811?

A 3-pole Contactor suitable for DC-1 applications where all three poles must be connected in series in a 1-pole configuration up to max 1000 VDC. Operated with wide control voltage range 24-60 V, DC

Specifications

General

Order code (ABB product ID)1SFL637025R6811
TypeGAF750-10-11-68
LifecycleActive (current ABB product)
Country of originIndia

Ordering

Minimum Order Quantity1 piece
Customs Tariff Number85364900

Dimensions

Product Net Width210 mm
Product Net Depth / Length242 mm
Product Net Height283 mm
Product Net Weight14 kg

Technical

Number of Main Contacts NO1
Number of Main Contacts NC0
Number of Auxiliary Contacts NO1
Number of Auxiliary Contacts NC1
Number of Poles1P
Rated Operational VoltageMain Circuit 1000 V
Conventional Free-air Thermal Current (I<sub>th</sub>)acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 1050 A
Rated Operational Current DC-1 (I<sub>e</sub>)(1000 V) 3 Poles in Series, 40 °C 1050 A, (1000 V) 3 Poles in Series, 55 °C 875 A, (1000 V) 3 Poles in Series, 70 °C 720 A, (220 V) 3 Poles in Series, 40 °C 1050 A, (220 V) 3 Poles in Series, 55 °C 875 A, (220 V) 3 Poles in Series, 70 °C 720 A, (400 V) 3 Poles in Series, 40 °C 1050 A, (400 V) 3 Poles in Series, 55 °C 875 A, (400 V) 3 Poles in Series, 70 °C 720 A, (600 V) 3 Poles in Series, 40 °C 1050 A, (600 V) 3 Poles in Series, 55 °C 875 A, (600 V) 3 Poles in Series, 70 °C 720 A
Rated Insulation Voltage (U<sub>i</sub>)acc. to UL/CSA 1000 V
Rated Impulse Withstand Voltage (U<sub>imp</sub>)Main Circuit 8 kV
Mechanical Durability3 million
Maximum Mechanical Switching Frequency300 cycles per hour
Coil Operating Limits(acc. to IEC 60947-4-1) 0.85 x Uc Min. ... 1.1 x Uc Max. (at θ ≤ 70 °C)
Rated Control Circuit Voltage (U<sub>c</sub>)DC Operation 24 ... 60 V
Coil ConsumptionHolding at Max. Rated Control Circuit Voltage DC 4.7 W, Pull-in at Max. Rated Control Circuit Voltage DC 1192 V·A, Pull-in at Max. Rated Control Circuit Voltage DC 1192 W
Power Lossat Rated Operating Conditions per Pole 50 W
Connecting Capacity Main CircuitBar 52 mm², Bar 50 mm², Rigid Al-Cable 300 mm², Rigid Al-Cable 3x185 mm², Rigid Cu-Cable 300 mm², Rigid Cu-Cable 3x185 mm²
Connecting Capacity Auxiliary CircuitFlexible with Ferrule 1x 0.75 ... 2.5 mm², Flexible with Ferrule 2x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.75 ... 2.5 mm², Flexible 2x0.75 ... 2.5 mm², Solid 2 x 1 ... 4 mm², Stranded 2 x 1 .... 4 mm²
Connecting CapacityBar 52 mm², Rigid Al-Cable 3x185 mm², Rigid Cu-Cable 3x185 mm²
Degree of Protectionacc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20, acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00
Connecting Terminals (delivered in open position) Main PolesM 3.5 (+,-) pozidriv 2 screw with cable clamp
Recommended Screw DriverMain Circuit M12, Control Circuit Pozidriv 2, Control Circuit M3.5
Tightening TorqueCable Lug 45 N·m, Main Circuit 45 N·m
Terminal TypeMain Circuit: Bars
Suitable for Product ClassBlock ContactorsBlock Contactors
Product NameBlock Contactor

Technical UL/CSA

Maximum Operating Voltage UL/CSAMain Circuit 1000 V
General Use Rating UL/CSA(1000 V DC) 900 A, (440 V DC) 900 A, (600 V DC) 900 A

Environmental

Ambient Air TemperatureClose to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25 ... 50 °C, Close to Contactor without Thermal O/L Relay (0.85 ... 1.1 Uc) -40 ... 70 °C, Close to Contactor for Storage -40 ... 70 °C, Operation -40 ... 70 °C, Storage -40 ... +70 °C
Maximum Operating Altitude PermissibleWithout Derating 3000 m
Resistance to Shock acc. to IEC 60068-2-27Shock Direction: A 5 g, Shock Direction: B1 5 g, Shock Direction: B2 5 g, Shock Direction: C1 5 g, Shock Direction: C2 5 g

Material Compliance

RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification CodeQ
ETIM 7EC002552 - Power contactor, DC switching
ETIM 8EC002552 - Power contactor, DC switching
ETIM 9EC002552 - Power contactor, DC switching
eClassV11.0 : 27371018
UNSPSC39121529
IDEA Granular Category Code (IGCC)4763 >> Power contactor, DC switching
