ABB 1SAZ411201R2001 – TA110DU-90M Thermal Overload Relay 65 ... 90 A

MPN: 1SAZ411201R2001 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ABB Thermal Overload Relays
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.75 kg
Country of origin	India
UPC / EAN	4013614570018

Shipping & availability

When can 1SAZ411201R2001 be shipped?

1SAZ411201R2001 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SAZ411201R2001 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SAZ411201R2001 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SAZ411201R2001, subject to availability and destination.

TA110DU-90M Thermal Overload Relay Trip class 10A, 65.0-90.0A

Specifications

General

Order code (ABB product ID)	1SAZ411201R2001
Type	TA110DU-90M
Lifecycle	Active (current ABB product)
Country of origin	India

Ordering

Minimum Order Quantity	1 piece
Customs Tariff Number	85364900

Dimensions

Product Net Width	80 mm
Product Net Height	120 mm
Product Net Depth / Length	120 mm
Product Net Weight	0.75 kg

Technical

Setting Range	65 ... 90 A
Rated Operational Voltage	Auxiliary Circuit 440 V DC, Auxiliary Circuit 500 V AC, Main Circuit 690 V AC, Main Circuit 440 V DC
Rated Operational Current (I<sub>e</sub>)	90 A
Rated Frequency (f)	Auxiliary Circuit 50 Hz, Auxiliary Circuit 60 Hz, Auxiliary Circuit DC, Main Circuit 60 Hz, Main Circuit 50 Hz, Main Circuit DC
Rated Impulse Withstand Voltage (U<sub>imp</sub>)	Auxiliary Circuit 6 kV, Main Circuit 6 kV
Rated Insulation Voltage (U<sub>i</sub>)	690 V
Number of Poles	3P
Number of Auxiliary Contacts NC	1
Number of Auxiliary Contacts NO	1
Number of Protected Poles	3
Conventional Free-air Thermal Current (I<sub>th</sub>)	Auxiliary Circuit NC 10 A, Auxiliary Circuit NO 6 A
Rated Operational Current AC-15 (I<sub>e</sub>)	(120 V) NC 3 A, (120 V) NO 1.5 A, (240 V) NC 3 A, (240 V) NO 1.2 A, (400 V) NC 0.75 A, (400 V) NO 0.37 A, (440 V) NC 0.75 A, (440 V) NO 0.37 A, (500 V) NC 0.3 A, (500 V) NO 0.25 A
Rated Operational Current DC-13 (I<sub>e</sub>)	(125 V) NC 0.25 A, (125 V) NO 0.25 A, (24 V) NC 1.25 A, (24 V) NO 1.25 A, (250 V) NC 0.12 A, (250 V) NO 0.04 A, (60 V) NC 0.25 A, (60 V) NO 0.25 A
Degree of Protection	Housing IP20, Main Circuit Terminals IP10
Pollution Degree	3
Connecting Capacity Auxiliary Circuit	Flexible with Ferrule 1/2x 0.75 ... 2.5 mm², Flexible 1/2x 0.75 ... 2.5 mm², Rigid 1/2x 0.75 ... 4 mm²
Connecting Capacity Main Circuit	Flexible 1x 16 ... 35 mm², Rigid 1x 16 ... 35 mm²
Tightening Torque	Auxiliary Circuit 1 ... 1.3 N·m, Main Circuit 7.2 ... 9.6 N·m
Wire Stripping Length	Auxiliary Circuit 9 mm, Main Circuit 25 mm
Recommended Screw Driver	Auxiliary Circuit Pozidriv 2, Main Circuit Hexagon 4
Power Loss	at Rated Operating Conditions per Pole 2.4 ... 4.5 W
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-4-1

Technical UL/CSA

Maximum Operating Voltage UL/CSA	Main Circuit 600 V AC
Connecting Capacity Main Circuit UL/CSA	Flexible 1/2x 6-2/0 AWG, Stranded 1/2x 6-2/0 AWG
Connecting Capacity Auxiliary Circuit UL/CSA	Flexible 1/2x 18-14 AWG, Stranded 1/2x 18-14 AWG
Tightening Torque UL/CSA	Auxiliary Circuit 12 in·lb

Environmental

Ambient Air Temperature	Operation -25 ... +55 °C, Operation Compensated -25 ... +55 °C, Storage -40 ... +70 °C
Ambient Air Temperature Compensation	Yes
Maximum Operating Altitude Permissible	2000 m
Resistance to Shock acc. to IEC 60068-2-27	11 ms Pulse 12g, 25g 2 shocks 13 ms
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Material Compliance

WEEE B2C / B2B	Business To Business
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)

External Classifications and Standards

Object Classification Code	F
ETIM 9	EC000106 - Thermal overload relay
ETIM 10	EC000106 - Thermal overload relay
eClass	V11.0 : 27371501
UNSPSC	39121520
IDEA Granular Category Code (IGCC)	5364 >> Overload relay

Downloads & documentation

Official documents from ABB, downloaded directly from the manufacturer.

Data sheets & manuals

Data Sheet, Technical Information (1SBC100187L0203)
Instructions and Manuals (2CDC106029M6801)

Certificates (5)

REACH Declaration (2CMT2021-006202)
RoHS Declaration (2CMT2021-006277)
CCC Certificate (2024010304659820)
Declaration of Conformity - CE (1SAD101100-3501)
UL Certificate (E48139-19960919)
