What is the Siemens 6ES7 135-6GB00-0BA1? Digital I/O Module
General information Technical Product Detail Page https://i.siemens.com/1P6ES7135-6GB00-0BA1 Product type designation AQ 2xI ST HW functional status from FS21 Firmware version V1.0.2 FW update possible Yes usable BaseUnits BU type A0, A1 Color code for module-specific color-coded label CC00 I&M data Yes; I&M0 to I&M3 Isochronous mode No Output range scalable No STEP 7 TIA Portal configurable/integrated from version V13 SP1 / - STEP 7 configurable/integrated from version V5.5 SP3 / - PROFIBUS from GSD version/GSD revision GSD Revision 5 PROFINET from GSD version/GSD revision GSDML V2.3 Oversampling No MSO No
CiR - Configuration in RUN Reparameterization possible in RUN No Calibration possible in RUN No
Supply voltage Rated value (DC) 24 V permissible range, lower limit (DC) 19.2 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Yes
Input current Current consumption, max. 110 mA
Address area Address space per module, max. 4 byte; + 1 byte for QI information
Hardware configuration Automatic encoding Yes Mechanical coding element Yes Type of mechanical coding element Type A
Analog outputs Number of analog outputs 2 Cycle time (all channels), min. 1 ms Analog output with oversampling No 0 to 20 mA Yes; 15 bit -20 mA to +20 mA Yes; 16 bit incl. sign 4 mA to 20 mA Yes; 14 bit for current output two-wire connection Yes with current outputs, max. 500 Ω with current outputs, inductive load, max. 1 mH Voltages at the outputs 30 V shielded, max. 1 000 m
Analog value generation for the outputs Resolution with overrange (bit including sign), max. 16 bit for resistive load 0.1 ms; Typical value for inductive load 0.5 ms
Errors/accuracies Linearity error (relative to output range), (+/-) 0.03 % Temperature error (relative to output range), (+/-) 0.005 %/K Crosstalk between the outputs, min. -50 dB Repeat accuracy in steady state at 25 °C (relative to output range), (+/-) 0.05 % Voltage, relative to output range, (+/-) 0.5 % Current, relative to output range, (+/-) 0.5 % Voltage, relative to output range, (+/-) 0.3 % Current, relative to output range, (+/-) 0.3 %
Interrupts/diagnostics/status information Diagnostics function Yes Substitute values connectable Yes Diagnostic alarm Yes Monitoring the supply voltage Yes Wire break Yes Group error Yes Overflow/Underflow Yes; module-wise Monitoring of the supply voltage (PWR-LED) Yes; green PWR LED Channel status display Yes; green LED for channel diagnostics No for module diagnostics Yes; green/red DIAG LED
Potential separation between the channels No between the channels and backplane bus Yes between the channels and the power supply of the electronics Yes
Isolation Isolation tested with 707 V DC (type test)
Standards, approvals, certificates environmental product declaration Yes — global warming potential, (total) [CO2 eq] 28.6 kg — global warming potential, (during production) [CO2 eq] 5.33 kg — global warming potential, (during operation) [CO2 eq] 23.6 kg — global warming potential, (after end of life cycle) [CO2 eq] -0.343 kg
Ambient conditions horizontal installation, min. -30 °C; < 0 °C as of FS03 horizontal installation, max. 60 °C vertical installation, min. -30 °C; < 0 °C as of FS03 vertical installation, max. 50 °C Installation altitude above sea level, max. 5 000 m; restrictions for installation altitudes > 2 000 m, see ET 200SP System Manual dew point, min. -60 °C; suitable for dry room applications
Dimensions Width 15 mm Height 73 mm Depth 58 mm
No matching specifications
Downloads & documentation Official documents from Siemens, downloaded directly from the manufacturer.
6ES7 135-6GB00-0BA1: frequently asked questions When can 6ES7 135-6GB00-0BA1 be shipped? 6ES7 135-6GB00-0BA1 is in stock and typically ships within 1 business day via UPS, DHL or FedEx, worldwide.
Can I pick up 6ES7 135-6GB00-0BA1 in person? Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available? Yes — alongside standard UPS, DHL and FedEx shipping, express (next-day) delivery is available at checkout for in-stock items like 6ES7 135-6GB00-0BA1.
My factory is down and I need this urgently — can you help? For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6ES7 135-6GB00-0BA1, subject to availability and destination.
Siemens 6ES7 135-6GB00-0BA1 €126.14
