What is the Siemens 6ES7142-5AF00-0BA0? Digital I/O Module
General information Technical Product Detail Page https://i.siemens.com/1P6ES7142-5AF00-0BA0 Product type designation DQ 8x24VDC/2A HW functional status FS06 Firmware version V2.0.x I&M data Yes; I&M0 to I&M3 STEP 7 TIA Portal configurable/integrated from version STEP 7 V13 SP1 or higher STEP 7 configurable/integrated from version V5.5 SP4 Hotfix 7 or higher PROFIBUS from GSD version/GSD revision GSD as of Revision 5 PROFINET from GSD version/GSD revision GSDML V2.3.1
Supply voltage power supply according to NEC Class 2 required No Rated value (DC) 24 V permissible range, lower limit (DC) 20.4 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Yes; against destruction; load increasing Rated value (DC) 24 V permissible range, lower limit (DC) 20.4 V permissible range, upper limit (DC) 28.8 V Reverse polarity protection Yes; against destruction; load increasing
Input current Current consumption (rated value) 40 mA; 40 mA (1L+) / 35 mA (2L+); without load from load voltage 1L+ (unswitched voltage) 4 A; Maximum value from load voltage 2L+, max. 4 A; Maximum value
Digital outputs Number of digital outputs 8 in groups of 4; 2 load groups for 4 outputs each Current-sourcing Yes output type acc. to IEC 61131, type 2 Yes Short-circuit protection Yes; per channel, electronic Response threshold, typ. 2.8 A Limitation of inductive shutdown voltage to 2L+ (-47 V) on lamp load, max. 10 W lower limit 12 Ω upper limit 4 kΩ for signal "1", min. L+ (-0.8 V) for signal "1" rated value 2 A for signal "1" permissible range, max. 2 A; with inductive load to IEC 60947-5-1, DC-13 / AC-15 for signal "0" residual current, max. 0.5 mA with resistive load, max. 100 Hz with inductive load, max. 0.1 Hz; 0.25 Hz at 25 °C on lamp load, max. 1 Hz Current per group, max. 4 A; For inductive load max. 2 channels per group unshielded, max. 30 m
Interrupts/diagnostics/status information Substitute values connectable Yes; channel by channel, parameterizable Diagnostic alarm Yes; Parameterizable Short-circuit Yes; Outputs to ground; module by module Channel status display Yes; green LED for module diagnostics Yes; green/red LED For load voltage monitoring Yes; green LED
Potential separation between the load voltages Yes between the channels, in groups of 4 between the channels and backplane bus Yes between the channels and the power supply of the electronics No; 4 channels are non-isolated and 4 channels are isolated from supply voltage 1L+
Isolation Isolation tested with 707 V DC (type test)
Degree and class of protection IP degree of protection IP65/67
Standards, approvals, certificates Suitable for safety-related tripping of standard modules Yes; from FS01 Performance level according to ISO 13849-1 PL d Category according to ISO 13849-1 Cat. 3 SIL acc. to IEC 62061 SIL 2 remark on safety-oriented shutdown https://support.industry.siemens.com/cs/de/en/view/39198632
Security signed firmware update Yes data integrity Yes
Ambient conditions min. -30 °C max. 55 °C Ambient air temperature-barometric pressure-altitude Up to max. 5 000 m, at installation height > 2 000 m additional restrictions
Connection method Design of electrical connection for the inputs and outputs M12, 5-pole Design of electrical connection for supply voltage M8, 4-pole ET-Connection M8, 4-pin, shielded
Dimensions Width 45 mm Height 159 mm Depth 40 mm
No matching specifications
Downloads & documentation Official documents from Siemens, downloaded directly from the manufacturer.
6ES7142-5AF00-0BA0: frequently asked questions When can 6ES7142-5AF00-0BA0 be shipped? 6ES7142-5AF00-0BA0 is in stock and typically ships within 1 business day via UPS, DHL or FedEx, worldwide.
Can I pick up 6ES7142-5AF00-0BA0 in person? Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available? Yes — alongside standard UPS, DHL and FedEx shipping, express (next-day) delivery is available at checkout for in-stock items like 6ES7142-5AF00-0BA0.
My factory is down and I need this urgently — can you help? For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6ES7142-5AF00-0BA0, subject to availability and destination.
Siemens 6ES7142-5AF00-0BA0 €227.90
