Siemens 6ES7136-6DC00-0CA0

Digital I/O Module

MPN: 6ES7136-6DC00-0CA0
Category: Digital I/O Modules

€210.94excl. VAT & shipping

In stock — 1 available·Ships within 1 business day

Need a larger quantity or a formal quote?

Request a Quote

12-month warranty
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 6ES7136-6DC00-0CA0?

Digital I/O Module

Specifications

General information

Technical Product Detail Page	https://i.siemens.com/1P6ES7136-6DC00-0CA0
Product type designation	F-DQ 8x24 V DC/0.5 A PP HF
Firmware version — FW update possible	Yes
usable BaseUnits	BU type A0
Color code for module-specific color-coded label	CC02
I&M data	Yes; I&M0 to I&M3
STEP 7 TIA Portal configurable/integrated from version	V14 SP1 with HSP 202
STEP 7 configurable/integrated from version	V5.5 SP4 HF5
PROFINET from GSD version/GSD revision	V2.31

Supply voltage

Rated value (DC)	24 V
permissible range, lower limit (DC)	19.2 V
permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
power supply according to NEC Class 2 required	No

Input current

Current consumption (rated value)	75 mA; without load
Current consumption, max.	21 mA; From the backplane bus

Output voltage

Rated value (DC)

24 V

Power

Power consumption from the backplane bus

70 mW

Power loss

Power loss, typ.

3 W

Address area

Inputs	6 byte; 5 bytes non-RIOforFA; 6 bytes RIOforFA
Outputs	6 byte; 5 bytes non-RIOforFA; 6 bytes RIOforFA

Hardware configuration

Automatic encoding	Yes
Electronic coding element type F	Yes

Digital outputs

Type of digital output	Transistor
Number of digital outputs	8
Digital outputs, parameterizable	Yes
Short-circuit protection	Yes
Response threshold, typ.	Min. 0.7 A
Open-circuit detection	No
Limitation of inductive shutdown voltage to	Typ. -39 V
Controlling a digital input	Yes; digital output, according to IEC 61131-2, type 0.5
with resistive load, max.	0.5 A
on lamp load, max.	2 W
lower limit	48 Ω
upper limit	12 000 Ω
for signal "1", min.	24 V; L+ (-0.5 V)
for signal "1" rated value	0.5 A
for signal "0" residual current, max.	0.5 mA
with resistive load, max.	30 Hz; Symmetrical
with inductive load, max.	0.1 Hz; according to IEC 60947-5-1, DC-13, symmetrical
with capacitive load, max.	2 Hz; Symmetrical
on lamp load, max.	10 Hz; Symmetrical
Current per channel, max.	0.5 A; note derating data in the manual
Current per module, max.	3 A; note derating data in the manual
— up to 40 °C, max.	3 A
— up to 50 °C, max.	2.5 A
— up to 60 °C, max.	2 A
— up to 50 °C, max.	2 A
shielded, max.	100 m
unshielded, max.	100 m

Interrupts/diagnostics/status information

Diagnostics function	Yes; See Chapter "Alarms/diagnostic messages" in the manual
Substitute values connectable	No
Diagnostic alarm	Yes
Hardware interrupt	No
RUN LED	Yes; green LED
ERROR LED	Yes; red LED
Monitoring of the supply voltage (PWR-LED)	Yes; green PWR LED
Channel status display	Yes; green LED
for channel diagnostics	Yes; red LED
for module diagnostics	Yes; green/red DIAG LED

Potential separation

between the channels	No
between the channels and backplane bus	Yes
between the channels and the power supply of the electronics	No

Isolation

Isolation tested with

707 V DC (type test)

Standards, approvals, certificates

Suitable for safety functions	Yes
environmental product declaration	Yes
— global warming potential, (total) [CO2 eq]	88.3 kg
— global warming potential, (during production) [CO2 eq]	13.1 kg
— global warming potential, (during operation) [CO2 eq]	76.6 kg
— global warming potential, (after end of life cycle) [CO2 eq]	-1.37 kg
Performance level according to ISO 13849-1	PLe
Category according to ISO 13849-1	Cat. 4
SIL acc. to IEC 61508	SIL 3
— Low demand mode: PFDavg in accordance with SIL3	< 6.00E-05
— High demand/continuous mode: PFH in accordance with SIL3	< 2.00E-09 1/h

Ambient conditions

horizontal installation, min.	0 °C
horizontal installation, max.	60 °C
vertical installation, min.	0 °C
vertical installation, max.	50 °C
Installation altitude above sea level, max.	4 000 m; restrictions for installation altitudes > 2 000 m, see ET 200SP System Manual

Dimensions

Width	15 mm
Height	73 mm
Depth	58 mm

Weights

Weight, approx.

48 g
