Capacitive Sensors Parts
Compare Capacitive Sensors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Order code (Pepperl+Fuchs part number) | Assured operating distance | Installation conditions: B | Installation conditions: F | MTTFd |
|---|---|---|---|---|---|
| CBB10-30GK60-E2 | 237549 | 0 ... 8.1 mm sa | 0 mm | 40 mm | 760 a |
| CCN15-30GS60-E2-V1 | 189963 | 0 ... 12.1 mm sa | 10 mm | 60 mm | 759 a |
| CCN15-30GS60-E2 | 189960 | 0 ... 12.1 mm sa | 10 mm | 60 mm | 750 a |
| CCN15-30GS60-E0 | 189959 | 0 ... 12.1 mm sa | 10 mm | 60 mm | — |
| CBN15-30GK60-E2 | 189951 | 0 ... 12.1 mm sa | 10 mm | 60 mm | 750 a |
| CBN15-30GK60-E0 | 189950 | 0 ... 12.1 mm sa | 10 mm | 60 mm | — |
| CBN10-F46-E0 | 051977 | 0 ... 7 mm sa | 5 mm | 20 mm / 50 mm | — |
| CBN10-F46-E2 | 051979 | 0 ... 7 mm sa | 5 mm | 20 mm / 50 mm | 1210 a |
Common to all listed parts
| Switching function | Normally open (NO) |
| Output polarity | DC |
| Lifecycle | Active (current Pepperl+Fuchs product) |
| Reverse polarity protection | reverse polarity protected |
| Short-circuit protection | pulsing |
| Off-state current TU =40 °C, switching element off | ≤ 100 µA |
| Time delay before availability | ≤ 50 ms tv |
| Switching state indicator | LED, yellow |
