Directional on/off valve Parts
Compare Directional on/off valve
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product family | Max. flow [l/min] | Supply voltage | Seals | Weight [kg] |
|---|---|---|---|---|---|
| R901374356 | WE10../E | 160.0 | 96 VDC | FKM | 5.5 |
| R901350365 | WE10../E | 160.0 | 96 VDC | NBR | 5.5 |
| R901537956 | WE10../E | 160.0 | 48 VDC | NBR | 5.6 |
| R901372869 | WE10../E | 160.0 | 24 VDC | NBR | 5.6 |
| R901350438 | WE10../E | 160.0 | 24 VDC | FKM | 5.51 |
| R901369093 | WE10../E | 160.0 | 24 VDC | NBR (HFC) | 4.78 |
| R901278776 | WE10../E | 160.0 | 24 VDC | NBR | 5.5 |
| R901401434 | WE10../E | 160.0 | 24 VDC | NBR | 5.6 |
| R901412936 | WE10../E | 160.0 | 24 VDC | NBR | 5.6 |
| R901436491 | WE10../E | 160.0 | 24 VDC | NBR | 5.7 |
| R901580981 | WE10../E | 160.0 | 24 VDC | NBR | 5.6 |
| R901453659 | WE10../E | 160.0 | 24 VDC | NBR | 5.5 |
| R901394262 | WE10../E | 160.0 | 220 VDC | NBR | 5.5 |
| R901374169 | WE10../E | 160.0 | 205 VDC | FKM | 5.6 |
| R901349609 | WE10../E | 160.0 | 205 VDC | NBR | 5.6 |
| R901350237 | WE10../E | 160.0 | 12 VDC | NBR | 5.6 |
| R901515134 | WE10../E | 160.0 | 24 VDC | NBR | 5.5 |
| R901457668 | WE10../E | 160.0 | 24 VDC | NBR | 5.2 |
| R901365307 | WE10../E | 160.0 | 205 VDC | NBR | 5.6 |
| R900915669 | WE 10...C | 120.0 | 230 VAC 50/60Hz | NBR | 4.35 |
| R900561079 | WE 10...C | 120.0 | 110…120 VAC 50/60 Hz | NBR | 4.4 |
| R988149271 | WE10../H | 135.0 | 24 VDC | NBR | 3.31 |
| R901554196 | WE10../E | 120.0 | 230 VAC 50/60Hz | NBR | 3.3 |
| R901560474 | WE10../E | 98.0 | 120 VAC 50/60Hz | NBR | 3.28 |
Common to all listed parts
| Connection diagram | ISO 4401-05-04-0-05 |
| Type of connection | Subplate mounting |
| Size | 10 |
| Type of actuation | with solenoid actuation |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
