Directional on/off valve Parts
Compare Directional on/off valve
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product family | Max. flow [l/min] | Supply voltage | Seals | Weight [kg] |
|---|---|---|---|---|---|
| R901032266 | WE6../E | 80.0 | 48 VDC | NBR | 1.92 |
| R900945776 | WE6../E | 80.0 | 26 VDC | NBR | 1.8 |
| R901026849 | WE 6…E..XE | 50.0 | 24 VDC | NBR | 4.04 |
| R900757936 | WE6../E | 80.0 | 24 VDC | NBR | 1.95 |
| R901236950 | WE6../E | 80.0 | 24 VDC | NBR | 2 |
| R901138323 | WE6../E | 80.0 | 24 VDC | NBR | 1.98 |
| R901535647 | WE 6…XN | 70.0 | 24 VDC | NBR | 2.75 |
| R901502701 | WE6../E | 80.0 | 24 VDC | NBR | 2.04 |
| R901235376 | WE6../E | 80.0 | 24 VDC | NBR | 2 |
| R901514820 | WE6../E | 80.0 | 24 VDC | FKM | 3.17 |
| R901327934 | WE6../E | 80.0 | 24 VDC | NBR | 3.18 |
| R901476611 | WE6../E | 80.0 | 24 VDC | FKM | 1.94 |
| R901231692 | WE6../E | 80.0 | 24 VDC | FKM | 1.8 |
| R901483983 | WE6../E | 80.0 | 24 VDC | NBR | 1.8 |
| R900934697 | WE6../E | 80.0 | 24 VDC | FKM | 1.95 |
| R900618358 | WE6../E | 80.0 | 24 VDC | NBR | 1.98 |
| R900975953 | WE6../E | 80.0 | 24 VDC | NBR | 1.96 |
| R901468825 | WE6../E | 80.0 | 24 VDC | FKM | 1.98 |
| R900770367 | WE6../E | 80.0 | 24 VDC | NBR | 1.95 |
| R978017758 | WE6../E | 80.0 | 24 VDC | NBR | 1.95 |
| R900564107 | WE6../E | 80.0 | 24 VDC | NBR | 1.98 |
| R900906673 | WE6../E | 80.0 | 24 VDC | NBR | 2.06 |
| R901409328 | WE6../E | 80.0 | 24 VDC | NBR | 2.08 |
| R901346714 | WE6../E | 80.0 | 24 VDC | NBR | 1.8 |
Common to all listed parts
| Connection diagram | ISO 4401-03-02-0-05 |
| Operating pressure, max. [bar] | 350.0 |
| Spool symbol | Symbol C |
| Size | 6 |
| Type of actuation | with solenoid actuation |
| Number of ports | 4 |
| Number of switching positions | 2 |
