Internal gear pumps Parts
























Compare Internal gear pumps
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Size | Direction of rotation | Seals | Weight [kg] | Max. flow [l/min] |
|---|---|---|---|---|---|
| R901392048 | 25 | clockwise rotation | FKM | 14.64 | — |
| R901147106 | 25 | clockwise rotation | FKM | 14.64 | 75.0 |
| R901282906 | 25 | counterclockwise rotation | FKM | 15.6 | 75.0 |
| R901283008 | 25 | counterclockwise rotation | FKM | 15.7 | 75.0 |
| R901340845 | 20 | clockwise rotation | NBR | 14.22 | 60.0 |
| R901505415 | 20 | clockwise rotation | FKM | 14.29 | — |
| R901147110 | 20 | clockwise rotation | FKM | 14.3 | 60.0 |
| R901340844 | 20 | clockwise rotation | NBR | 14.34 | 60.0 |
| R901330079 | 20 | clockwise rotation | NBR | 14.06 | 60.0 |
| R901500524 | 20 | clockwise rotation | FKM | 14.33 | — |
| R901147100 | 20 | clockwise rotation | FKM | 14.33 | 60.0 |
| R901147105 | 20 | clockwise rotation | FKM | 14.08 | 60.0 |
| R901537415 | 20 | counterclockwise rotation | NBR | 15 | 60.0 |
| R901282905 | 20 | counterclockwise rotation | FKM | 14.5 | 60.0 |
| R901283006 | 20 | counterclockwise rotation | FKM | 15.14 | 60.0 |
| R901281698 | 16 | clockwise rotation | FKM | 7.4 | 48.0 |
| R901248934 | 16 | clockwise rotation | NBR | 7.1 | 48.0 |
| R901433808 | 16 | clockwise rotation | FKM | 7.34 | 48.0 |
| R900961558 | 16 | counterclockwise rotation | FKM | 7.24 | 48.0 |
| R901316746 | 16 | clockwise rotation | NBR | 7.94 | 48.0 |
| R900951305 | 16 | clockwise rotation | FKM | 7.96 | 48.0 |
| R901465533 | 16 | clockwise rotation | FKM | 3.5 | 48.0 |
| R900961561 | 16 | clockwise rotation | FKM | 7.36 | 48.0 |
| R900961555 | 16 | counterclockwise rotation | FKM | 7.72 | 48.0 |
Common to all listed parts
| Displacement type | constant |
| Product family | PGH |
| Operating pressure, max. [bar] | 315.0 |
| Through-drive | with |
