3VA Molded Case Circuit Breakers up to 1600 A, IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 1600 A, IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | power loss [W] / maximum | Net Weight | operational current — at 55 °C | adjustable response value setting current (Ir) / of the L-trip / with I2t characteristic — minimum | adjustable response value setting current (Ii) / for I-tripping — minimum |
|---|---|---|---|---|---|
| 3VA1163-4ED16-0AA0 | 5.77 W | 397 g | 62 A | 63 A | 630 A |
| 3VA1163-4ED12-0AA0 | 5.77 W | 383 g | 62 A | 63 A | 630 A |
| 3VA1163-3GF46-0AA0 | 17.3 W | 1.268 kg | 62 A | 44 A | 315 A |
| 3VA1110-4EE46-0AA0 | 25 W | 1.297 kg | 98 A | 70 A | 1 000 A |
| 3VA1110-4ED46-0AA0 | 25 W | 1.236 kg | 98 A | 100 A | 1 000 A |
| 3VA1332-4EF42-0AA0 | 80.1 W | 6.301 kg | 313 A | 224 A | 1 600 A |
| 3VA2216-6HN42-0AA0 | 19.7 W | 3.2 kg | 160 A | 63 A | 1 920 A |
| 3VA2140-5JP46-0AA0 | 1.6 W | 3.2 kg | 40 A | 16 A | 60 A |
| 3VA2140-5JP42-0AA0 | 1.6 W | 3.2 kg | 40 A | 16 A | 60 A |
| 3VA2140-5HM42-0AA0 | 1.6 W | 2.807 kg | 40 A | 16 A | 60 A |
| 3VA2140-5HM36-0AA0 | 1.6 W | 2.299 kg | 40 A | 16 A | 60 A |
| 3VA2463-0KQ42-0AA0 | 162 W | 6.35 kg | 540 A | 252 A | 945 A |
| 3VA2463-0KQ32-0AA0 | 162 W | 5.05 kg | 540 A | 252 A | 945 A |
| 3VA2463-0KP42-0AA0 | 162 W | 6.35 kg | 540 A | 252 A | 945 A |
| 3VA2463-0KP32-0AA0 | 162 W | 5.223 kg | 540 A | 252 A | 945 A |
| 3VA2463-0HN42-0AA0 | 162 W | 6.35 kg | 575 A | 250 A | 5 670 A |
| 3VA2450-7MP32-0AA0 | 99 W | 4.8 kg | 477 A | 200 A | 1 500 A |
| 3VA2450-7MN32-0AA0 | 99 W | 4.961 kg | 495 A | 200 A | 7 500 A |
| 3VA1010-3ED32-0AA0 | 25 W | 915 g | 98 A | 100 A | 1 000 A |
| 3VA1116-4ED22-0AA0 | 25.34 W | 669 g | 158 A | 160 A | 1 600 A |
| 3VA1116-4ED16-0AA0 | 12.67 W | 0.36 kg | 158 A | 160 A | 1 600 A |
| 3VA1116-4ED12-0AA0 | 12.67 W | 400 g | 158 A | 160 A | 1 600 A |
| 3VA1116-3GF46-0AA0 | 38 W | 1.343 kg | 158 A | 112 A | 800 A |
| 3VA1120-5ED32-0AA0 | 12 W | 915 g | 20 A | 20 A | 320 A |
Common to all listed parts
| product designation | Molded case circuit breaker |
| product feature / for L-tripping / can be switched on/off | No |
| product component — undervoltage release | No |
| product component — voltage trigger | No |
| product component — trip indicator | No |
| arrangement of electrical connectors / for main current circuit | Front terminal |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
