PV Cumulative Fuses Parts

Siemens

PV fuse link, with blade contacts, NH1XL, In: 100 A, gPV

Siemens

PV fuse link, with blade contacts, NH1, In: 100 A, gPV

Siemens

PV fuse link, with blade contacts, NH1XL, In: 80 A, gPV

Siemens

PV fuse link, with blade contacts, NH2L, In: 400 A, gPV

Siemens

PV fuse link, with blade contacts, NH1XL, In: 125 A, gPV

Siemens

PV fuse link, with blade contacts, NH1, In: 125 A, gPV

Siemens

PV fuse link, with blade contacts, NH2XL, In: 315 A, gPV

Siemens

PV fuse link, with blade contacts, NH2L, In: 315 A, gPV

Siemens

PV fuse link, with blade contacts, NH1XL, In: 200 A, gPV

Siemens

PV fuse link, with blade contacts, NH1L, In: 200 A, gPV

Compare PV Cumulative Fuses

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	size of fuse system according to EN 60269-1	power loss [W]	power loss [W] — for rated value of the current at AC in hot operating state per pole	power loss [W] — maximum	Net Weight
3NE1221-5E	NH1XL	30 W	30 W	30 W	1.003 kg
3NE1221-4	NH1	24 W	24 W	24 W	0.615 kg
3NE1220-5E	NH1XL	25 W	25 W	25 W	0.994 kg
3NE1332-4D	NH2L	82 W	82 W	82 W	1.097 kg
3NE1222-5E	NH1XL	29 W	29 W	29 W	1.001 kg
3NE1222-4	NH1	26 W	26 W	26 W	606 g
3NE1330-5E	NH2XL	63 W	63 W	63 W	1.263 kg
3NE1330-4D	NH2L	73 W	73 W	73 W	1.081 kg
3NE1225-5E	NH1XL	41 W	41 W	41 W	1.002 kg
3NE1225-4D	NH1L	51 W	51 W	51 W	839 g

product designation	PV fuse link
design of the product	with blade contacts without slots
design of an identification indicator	front indicator
design of the switching contact	with blade contacts
design of the fuse link	Photovoltaic fuse, LV HRC design
operating class of the fuse link	gPV
varying load factor (WL)	1
type of voltage of the operating voltage	DC
