AM8372 Parts
Compare AM8372
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Rated torque | Peak torque | Rated speed | Rated power | Standstill current |
|---|---|---|---|---|---|
| AM8372-wVyz | 116 Nm | 169 Nm | 3000 min-1 | 36.5 kW | 92.1 A |
| AM8372-wTyz | 119 Nm | 172 Nm | 1500 min-1 | 18.7 kW | 48.9 A |
| AM8372-wRyz | 117 Nm | 173 Nm | 850 min-1 | 10.4 kW | 26.8 A |
Common to all listed parts
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Rotor moment of inertia | 92.2 kgcm² |
| Cooling | water cooling |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus in preparation |
| Protection rating | IP54, IP65 (shaft seal) |
| Design form | flange-mounted according to IM B5, IM V1, IM V3 |
