AM8363 Parts
Compare AM8363
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Rated speed | Rated power | Standstill current | Peak current | Torque constant |
|---|---|---|---|---|---|
| AM8363-wQyz | 1200 min-1 | 8.68 kW | 21.7 A | 38.9 A | 3.44 Nm/A |
| AM8363-wTyz | 2600 min-1 | 18.8 kW | 45.3 A | 80.9 A | 1.65 Nm/A |
| AM8363-wUyz | 4900 min-1 | 14.5 kW | 61.7 A | 130 A | 0.982 Nm/A |
Common to all listed parts
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Peak torque | 111 Nm |
| Rotor moment of inertia | 29.5 kgcm² |
| Cooling | water cooling |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus in preparation |
| Protection rating | IP54, IP65 (shaft seal) |
