Reyrolle 7SR10 Argus - 4xI, non-directional Parts
Compare Reyrolle 7SR10 Argus - 4xI, non-directional
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | product feature / conformal coating | design of the product | number of parameter sets | undervoltage protection (ANSI 27) | number of digital inputs / maximum |
|---|---|---|---|---|---|
| 7SR1004-3KB20-2CA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3JB20-2DB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3JB20-2DA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3JB20-2CB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1002-1KA10-2CA0 | No | Non directional Overcurrent relay | 2 | No | 3 |
| 7SR1002-1JB10-2DA0 | No | Non directional Overcurrent relay | 2 | No | 3 |
| 7SR1002-1JB10-2CA0 | No | Non directional Overcurrent relay | 2 | No | 3 |
| 7SR1003-1JA20-2DA0 | No | Non directional Overcurrent relay | 2 | No | 6 |
| 7SR1003-1JA20-2CB0 | Yes | Non directional Overcurrent relay | 2 | No | 6 |
| 7SR1003-1JA20-2CA0 | No | Non directional Overcurrent relay | 2 | No | 6 |
| 7SR1004-4LA20-2DA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-4LA20-2CB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-4LA20-2CA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-4JA20-2CA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3LB20-2DB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3LB20-2DA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3LB20-2CB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3LB20-2CA0 | No | Directional Overcurrent relay | 4 | Yes | 9 |
| 7SR1004-3LA20-2DB0 | Yes | Directional Overcurrent relay | 4 | Yes | 9 |
Common to all listed parts
| number of function keys | 7 |
| number of LEDs | 10 |
| type of measured value detection / of operational measured value / standard | Yes |
| type of measured value detection / expanded / min./max. values, mean values | No |
| switching statistics | Yes |
| circuit breaker monitoring | Yes |
| product feature / logic editor | Yes |
| control | Yes |
