Compare CPUs
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Fuse | Temperature – Horizontal mounting orientation | Temperature – Derating | Temperature – Storage | Weight |
|---|
| X20SL8110 | - | 0 to 60°C | - | -40 to 85°C | 190 g |
| X20SL8101 | Integrated, cannot be replaced | 0 to 60°C | See section "Derating". | -40 to 85°C | 190 g |
| X20SL8100 | - | 0 to 60°C | - | -40 to 85°C | 190 g |
| X20SL8000 | Integrated, cannot be replaced | 0 to 55°C | - | -25 to 70°C | 290 g |
| X20SL8001 | Integrated, cannot be replaced | 0 to 55°C | - | -25 to 70°C | 290 g |
| X20SL8010 | Integrated, cannot be replaced | 0 to 55°C | - | -25 to 70°C | 290 g |
| X20SL8011 | Integrated, cannot be replaced | 0 to 55°C | - | -25 to 70°C | 290 g |
| X20SL8201 | Required line fuse: Max. 10 A slow-blow | — | — | — | 190 g |
Common to all listed parts
| Interfaces | POWERLINK |
| System module | CPU |
| Cooling | Fanless |
| Status indicators | CPU function, POWERLINK, SafeKEY |
| Reverse polarity protection | Yes |
| Transfer rate | 100 Mbit/s |
| Installation elevation above sea level | 0 to 2000 m, no limitation |
| Degree of protection per EN 60529 | IP20 |
