8LTQC (size C) Parts
Compare 8LTQC (size C)
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal torque M n [Nm] | Nominal power P N [W] | Nominal current I N [A] | Stall current I 0 [A] | Maximum current I max [A] |
|---|---|---|---|---|---|
| 8LTQC3.ee001ffgg-0 | 108.1 | 1132 | 2.2 | 2.4 | 10.2 |
| 8LTQC3.ee003ffgg-0 | 100.05 | 3143 | 6.1 | 7.1 | 30.7 |
| 8LTQC3.ee005ffgg-0 | 88.55 | 4636 | 9.1 | 11.8 | 51.2 |
| 8LTQC4.ee001ffgg-0 | 211.5 | 2215 | 4.3 | 4.6 | 20.9 |
| 8LTQC4.ee003ffgg-0 | 195.75 | 6150 | 12 | 13.8 | 62.6 |
| 8LTQC4.ee005ffgg-0 | 173.25 | 9071 | 17.7 | 23 | 104.3 |
| 8LTQC5.ee001ffgg-0 | 305.5 | 3199 | 6.3 | 6.7 | 31.3 |
| 8LTQC5.ee003ffgg-0 | 282.75 | 8883 | 17.4 | 20 | 93.8 |
| 8LTQC5.ee005ffgg-0 | 250.25 | 13103 | 25.6 | 33.3 | 156.4 |
| 8LTQC6.ee001ffgg-0 | 394.8 | 4134 | 8.1 | 8.6 | 41.7 |
| 8LTQC6.ee003ffgg-0 | 365.4 | 11479 | 22.4 | 25.8 | 125.1 |
| 8LTQC6.ee005ffgg-0 | 323.4 | 16933 | 33.1 | 43 | 208.4 |
| 8LTQC7.ee001ffgg-0 | 479.4 | 5020 | 9.8 | 10.4 | 51.9 |
| 8LTQC7.ee003ffgg-0 | 443.7 | 13939 | 27.3 | 31.3 | 155.8 |
| 8LTQC7.ee005ffgg-0 | 392.7 | 20562 | 40.2 | 52.2 | 259.6 |
| 8LTQC8.ee001ffgg-0 | 564 | 5906 | 11.5 | 12.3 | 62.5 |
| 8LTQC8.ee003ffgg-0 | 522 | 16399 | 32.1 | 36.9 | 187.6 |
Common to all listed parts
| Number of pole pairs | 15 |
| Maximum speed n max [rpm] | 700 |
| Holding torque of brake M Br [Nm] | 0 |
| Mass of brake [kg] | 0 |
| Moment of inertia of brake J Br [kgcm 2] | 0 |
