Mitsubishi Electric TH-T18BC

Mitsubishi Low-voltage switchgear Thermal Overload Relay

MPN
TH-T18BC
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric TH-T18BC?

The Mitsubishi Electric TH-T18BC is a thermal Overload Relay in the Low-voltage switchgear. Overload Protection Adjustment Range of Setting Current:0.1 to 18A 3-Pole 2-Element Terminal Covers(with Wiring Streamlining Terminal) For Magnetic Starters. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineOverload Protection Adjustment Range of Setting Current:0.1 to 18A 3-Pole 2-Element Terminal Covers(with Wiring Streamlining Terminal) For Magnetic Starters

Specifications

Product SpecificationStandard Type
Rated Insulation Voltage Ui [V]690
Elements2
Protection ModeOverload Protection
Adjustment Range of Setting Current [A]0.1 to 18
Tripping Class10A
Heater Designation [A]: Category-10.12 to 9
Heater Designation [A]: Category-211
Heater Designation [A]: Category-315
Combined Magnetic Contactor Frame: Category-1T10,T12,T20
Combined Magnetic Contactor Frame: Category-2T12,T20
Combined Magnetic Contactor Frame: Category-3T20
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC550V0.3
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC550V0.3
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC24V0.5
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC220V0.1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC24V0.5
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC220V0.1
Conventional Free Air Thermal Current [A]2
Minimal Applicable Load20V 5mA
Contact Arrangements (Valid)1NO1NC
Function: Terminal CoversYes
Function: Wiring Streamlining TerminalYes
Independent MountingNot Available(Enabled by Combining with UT-HZ18)
Terminal Screw Size: Main Circuit (Load Side)M3.5
Terminal Screw Size: Operating CircuitM3.5
