Kinetix & Legacy Servo Drives, 2090 Motion Cables Parts
Compare Kinetix & Legacy Servo Drives, 2090 Motion Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Drive-end Connector Type | AWG size | Cable length | Cable style | Nominal cross section conductor (AWG) |
|---|---|---|---|---|---|
| 2090-CSBM1DF-18AA27 | Flying Lead at 5500 Drive End | 18 AWG | 27 m | Standard, non-flexible | 1.62 |
| 2090-CSBM1DF-18AA13 | — | 18 AWG | 13 m | Standard, Non-flex | 1.62 |
| 2090-CSBM1DG-18AF15 | Drive-end, long flying-leads | 18 AWG | 15 m | Continuous-flex | 1.62 |
| 2090-CSBM1DG-18AF06 | Drive-end, long flying-leads | 18 AWG | 6 m | Continuous-flex | 1.62 |
| 2090-CSBM1DG-18AA02 | — | 18 AWG | 2 m | Standard, non-flexible | 1.62 |
| 2090-CSBM1E1-10AF02 | — | 10 AWG | 2 m | Continuous-flexible | 10.38 |
| 2090-CSBM1DG-18AA09 | Drive-end, long flying-leads | 18 AWG | 9 m | Standard, Non-flex | 1.62 |
| 2090-CSBM1E1-06AF15 | Extension Receptor | 6 AWG | 15 m | Continuous-flex | 26.25 |
| 2090-CSBM1DG-14AF17 | Drive-End, Flying Lead, hybrid | 14 AWG | 17 m | Continuous-flex | 4.1 |
| 2090-CSBM1DG-14AF26 | Drive-End, Flying Lead, hybrid | 14 AWG | 26 m | Continuous-flex | 4.1 |
| 2090-CSBM1DG-14AF06 | Drive-End, Flying Lead, hybrid | 14 AWG | 6 m | Continuous-flex | 4.1 |
| 2090-CSBM1DG-14AF16 | — | 14 AWG | 16 m | Continuous-flexible | 4.1 |
| 2090-CSBM1DG-14AF10 | Drive-end, long flying-leads | 14 AWG | 10 m | Continuous-flex | 4.1 |
| 2090-CSBM1E1-14AF02 | Extension Receptor | 14 AWG | 2 m | Continuous-flex | 4.1 |
| 2090-CSBM1E1-14AF07 | Extension Receptor | 14 AWG | 7 m | Continuous-flex | 4.1 |
| 2090-CSBM1E1-14AF12 | Extension Receptor | 14 AWG | 12 m | Continuous-flex | 4.1 |
| 2090-CSWM1DE-14AA55 | Flying Lead at 5700 Drive End | 14 AWG | 55 m | Standard, Non-flex | 4.1 |
| 2090-CSWM1DE-14AA24 | Drive-end, connector kit | 14 AWG | 24 m | Standard, Non-flex | 4.1 |
| 2090-CSWM1DE-14AA19 | Drive-end, connector kit | 14 AWG | 19 m | Standard, Non-flex | 4.1 |
| 2090-CSBM1E1-14AF01 | Extension Receptor | 14 AWG | 1 m | Continuous-flex | 4.1 |
| 2090-CSWM1DE-14AA45 | Drive-end, connector kit | 14 AWG | 45 m | Standard, non-flexible | 4.1 |
| 2090-CSBM1DE-18AF32 | Drive-end, connector kit | 18 AWG | 32 m | Continuous-flex | 1.62 |
| 2090-CSWM1DE-14AA32 | — | 14 AWG | 32 m | Standard, non-flexible | 4.1 |
| 2090-CSBM1DE-18AF24 | Drive-end, connector kit | 18 AWG | 24 m | Continuous-flex | 1.62 |
Common to all listed parts
| Lifecycle | Active |
| Repair options available | No |
| Accessory component | Cable |
| Color cable code | RAL2003 |
| Colour outer sheath | Orange |
| Conductor material | Copper |
| Conductor surface | Tinned |
| Core color | White/blue |
