800FD Monolithic Push Buttons Parts
























Compare 800FD Monolithic Push Buttons
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Latch material | Operator cap color | Termination style | Contact block configuration | Operator function |
|---|---|---|---|---|---|
| 800FD-P4D1 | Plastic (monolithic) | Red | Screw | — | — |
| 800FD-SL22R10 | Plastic | Black | Screw for ring lugs | 1 NO | Spring return from left, 2 position |
| 800FD-SL22R20 | Plastic | Black | Screw for ring lugs | 2 NO | Spring return from left, 2 position |
| 800FD-SL22R02 | Plastic | Black | Screw for ring lugs | 2 NC | Spring return from left, 2 position |
| 800FD-SB32R02 | Plastic | Black | Screw for ring lugs | 2 NC | Spring return from both, 3 position |
| 800FD-SM22R10 | Plastic | Black | Screw for ring lugs | 1 NO | Maintained, 2 position |
| 800FD-P6D2R | Plastic (monolithic) | Blue | Screw ring lugs | — | — |
| 800FD-P5D3R | Plastic (monolithic) | Yellow | Screw ring lugs | — | — |
| 800FD-SM22R02 | Plastic | Black | Screw for ring lugs | 2 NC | Maintained, 2 position |
| 800FD-SL32R20 | Plastic | Black | Screw for ring lugs | 2 NO | Spring return from left, 3 position |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | June 30, 2025 |
| Replacement category (Rockwell) | Direct Replacement |
| Repair options available | No |
| Hole diameter | 22.5 mm |
| Humidity | ≤95% RH from 25...60 °C (77...140 °F) |
| Operating temperature | -25 °C |
| Shock | 100 G |
