800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Replacement category (Rockwell) | Contact block configuration | Illumination module input voltage | Illumination module termination wire range | Operator cap color |
|---|---|---|---|---|---|
| 800H-FRXJMP16RA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Red |
| 800H-FRXJTQ12GD4 | Functional Replacement | 1-NCLB standard contact | 12V AC/DC | 14 - 18 AWG (x2) | Green |
| 800H-FRXJTP46RA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 480V AC @ 50/60Hz | 20 - 18 AWG (x2) | Red |
| 800H-FRXJTQ10AA5 | Functional Replacement | 2-NCLB standard contact | 120V AC/DC | 14 - 18 AWG (x2) | Amber |
| 800H-FRXJTQ10AA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 120V AC/DC | 14 - 18 AWG (x2) | Amber |
| 800H-FRXJTP16GA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Green |
| 800H-FRXJTP16G | Functional Replacement | No contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Green |
| 800H-FRXJTP16A | Functional Replacement | No contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber |
| 800H-FRXJTP16BA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Blue |
| 800H-FRXJT9D4 | Direct Replacement | 1-NCLB standard contact | — | — | Yellow |
| 800H-FRXTQ24WD4 | Functional Replacement | 1-NCLB standard contact | 24V AC/DC | 17 - 18 AWG (x2) | White |
| 800H-FRXTQ24RD4V | Functional Replacement | 1-NCLB PenTUFF contact | 24V AC/DC | 17 - 18 AWG (x2) | Red |
| 800H-FRXTQ24RAV | Functional Replacement | 1-NO 1-NC PenTUFF contacts | 24V AC/DC | 17 - 18 AWG (x2) | Red |
| 800H-FRXTQ24RD2V | Functional Replacement | 1-NC PenTUFF contact | 24V AC/DC | 17 - 18 AWG (x2) | Red |
| 800H-FRXTP46AA5 | Functional Replacement | 2-NCLB standard contact | 480V AC @ 50/60Hz | 20 - 18 AWG (x2) | Amber |
| 800H-FRXTP26XD4 | Functional Replacement | 1-NCLB standard contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | No lens cap |
| 800H-FRXTP26XA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | No lens cap |
| 800H-FRXTP16XA2 | Functional Replacement | 2-NO standard contacts | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | No lens cap |
| 800H-FRXTP26RA5 | Functional Replacement | 2-NCLB standard contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Red |
| 800H-FRXTP26GA5 | Functional Replacement | 2-NCLB standard contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Green |
| 800H-FRXTP26GA1 | Functional Replacement | 1-NCLB 1-NO standard contacts | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Green |
| 800H-FRXNQ10BA | Functional Replacement | 1-NO 1-NC standard contacts | 120V AC/DC | 14 - 18 AWG (x2) | Blue |
| 800H-FRXTP26AA5 | Functional Replacement | 2-NCLB standard contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Amber |
| 800H-FRXTP16WD4 | Functional Replacement | 1-NCLB standard contact | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | White |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | March 31, 2025 |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hazardous location rating | false |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Operating temperature | -25 °C |
