800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Contact block operational voltage, max | Illumination module input voltage | Illumination module termination wire range | Operator cap color | Operator function |
|---|---|---|---|---|---|
| 800H-PRB16RA2 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Red | Momentary contact |
| 800H-PRB16GD2 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Green | Momentary contact |
| 800H-PRBD16GD1 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Green | Momentary contact |
| 800H-PRBD16B | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Blue | Momentary contact |
| 800H-PRBD16 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | No Cap | Momentary contact |
| 800H-PRB46B | 600V AC @ 600V DC | 480V AC @ 50/60Hz | 20 - 18 AWG (x2) | Blue | Momentary contact |
| 800H-PRB26W | 600V AC @ 600V DC | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | White | Momentary contact |
| 800H-PRB26RD2 | 600V AC @ 600V DC | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Red | Momentary contact |
| 800H-PRB16AD2 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber | Momentary contact |
| 800H-PRB16CD1 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Clear | Momentary contact |
| 800H-PRB16C | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Clear | Momentary contact |
| 800H-PRB16AG1 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber | Momentary contact |
| 800H-PRB16AD1R | 150V AC @ 30V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber | Momentary contact |
| 800H-PRB16AAV | 300V AC @ 150V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber | Momentary contact |
| 800H-PRB16AA4 | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Amber | Momentary contact |
| 800H-PRBD24R | 600V AC @ 600V DC | 24V AC/DC | 17 - 18 AWG (x2) | Red | Momentary contact |
| 800H-PRBD24G | 600V AC @ 600V DC | 24V AC/DC | 17 - 18 AWG (x2) | Green | Momentary contact |
| 800H-PRBD24B | 600V AC @ 600V DC | 24V AC/DC | 17 - 18 AWG (x2) | Blue | Momentary contact |
| 800H-PRBD16W | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | White | Momentary contact |
| 800H-PRBT16R | 600V AC @ 600V DC | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) | Red | Momentary contact |
| 800H-JR2KD7HR | 150V AC @ 30V DC | — | — | Black with white Insert | Maintained |
| 800H-FRXJT1D1 | 600V AC @ 600V DC | — | — | Green | 2-position |
| 800H-FRXJTQ10WD4 | 600V AC @ 600V DC | 120V AC/DC | 14 - 18 AWG (x2) | White | 2-position |
| 800H-FRXJMP26RA7 | 600V AC @ 600V DC | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) | Red | 3-position |
Common to all listed parts
| Repair options available | No |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
| Contact block termination wire range | 14 - 18 AWG (x2) |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Operating temperature | -25 °C |
| Operator construction/material | Plastic |
