Stainless Steel Parts
Compare Stainless Steel
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Catalog Number | Power Factor | Rated Efficiency | Product Net Weight | Dimension Diagram |
|---|---|---|---|---|---|
| CESSWDM3554-H | CESSWDM3554-H | 75 % | 86.50 % | 45 lb | 35LYE6084 |
| CESSWDM3713T | CESSWDM3713T | 90 % | 91.70 % | 187 lb | 37LYJ639 |
| CESSWDM3611T | CESSWDM3611T | 76 % | 89.50 % | 102 lb | 36LYL738 |
| CESSWDM3610T | CESSWDM3610T | 87 % | 88.50 % | 90 lb | 36LYL738 |
| CESSWDM3615T | CESSWDM3615T | 81 % | 89.50 % | 112 lb | 36LYL738 |
| CSSWDM3538 | CSSWDM3538 | 62 % | 78.20 % | 37 lb | 35LYV814 |
| CSSWDM3537-H | CSSWDM3537-H | 75 % | 72 % | 37 lb | 35LY-000-350 |
| VSSFWDM3538 | VSSFWDM3538 | 62 % | 78.20 % | 40 lb | 35LYW179 |
| VESSWDM3546 | VESSWDM3546 | 66 % | 85.50 % | 44 lb | 35LYV824 |
| CESSWDM3545-H | CESSWDM3545-H | 88 % | 84 % | 38 lb | 35LY-000-350 |
| CESSWDM3546-5 | CESSWDM3546-5 | 76 % | 85.50 % | 46 lb | 35LYW899 |
| CESSWDM3546-H | CESSWDM3546-H | 70 % | 87.50 % | 41 lb | 35LYE6083 |
| CSSWDM3542 | CSSWDM3542 | 78 % | 82.50 % | 42 lb | 35LYV814 |
| CSSWDM3538-H | CSSWDM3538-H | 62 % | 80 % | 33 lb | 35LY-000-350 |
| VESSWDM3558T | VESSWDM3558T | 81 % | 86.50 % | 45 lb | 35LYVV821 |
| VESSWDM3554T | VESSWDM3554T | 72 % | 86.50 % | 45 lb | 35LYVV821 |
| VESSWDM3559T | VESSWDM3559T | 91 % | 86.50 % | 64 lb | 35LYVV821 |
| CESSWDNM3555-H | CESSWDNM3555-H | 85 % | 86.50 % | 61 lb | 35LY-000-350 |
| VESSWDM3546T | VESSWDM3546T | 70 % | 87.50 % | 44 lb | 35LYVV821 |
| CESSWDM3545 | CESSWDM3545 | 82 % | 82.50 % | 39 lb | 35LYV814 |
| CESSWDM3546 | CESSWDM3546 | 66 % | 85.50 % | 41 lb | 35LYW899 |
| CESSWDM3615T-5 | CESSWDM3615T-5 | 81 % | 89.50 % | 112 lb | 36LYL738 |
| CESSWDM3611T-5 | CESSWDM3611T-5 | 76 % | 89.50 % | 92 lb | 36LYL738 |
| CESSWDM3613T-5 | CESSWDM3613T-5 | 90 % | 90.20 % | 106 lb | 36LYL738 |
Common to all listed parts
| Brand / Label | Baldor-Reliance |
| Country or Territory of Origin | United States |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Ambient Temperature | 40 °C |
| Duty Time | 60 Min |
| Number of Phases | 3-phase |
| Number of Speeds | Single Speed |
