Compare Belt section accumulation roller chain
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Length min [L min] [mm] | Track width in direction of transport [b min] [mm] | Section load in accumulation operation [kg] | Voltage at 60 Hz [V] |
|---|
| 3842998939 | 650 | 400 | 1200 | — |
| 3842998938 | 300 | 160 | 700 | 220; 400; 460; 575 |
| 3842998937 | 300 | 160 | 300 | 460; 575; 220; 400 |
Common to all listed parts
| Condition on delivery | Assembled |
| ESD | Yes |
| Length max [l max] [mm] | 6000 |
| Track width in direction of transport [b max] [mm] | 1200 |
| Conveyor medium | Accumulation roller chain (suitable for use in an EPA) |
| Weight [kg] | 0 |
