Electromechanical cylinders EMC Parts
Compare Electromechanical cylinders EMC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal size [mm] | Maximum permissible axial force Fmax [N] | Dynamic load capacity C [N] | Maximum travel range smax [mm] | Maximum permissible linear speed vmax [m/s] |
|---|---|---|---|---|---|
| R156070010 | 100XC | 56000 | 104900.0 | 1500.0 | 1.0 |
| R156060010 | 100 | 29000 | 42100.0 | 1500.0 | 1.47 |
| R156050010 | 080 | 22000 | 26000.0 | 1500.0 | 1.6 |
| R156040010 | 063 | 15900 | 17200.0 | 1200.0 | 1.38 |
| R156030010 | 050 | 7800 | 15400.0 | 900.0 | 1.27 |
| R156020010 | 040 | 4500 | 13300.0 | 750.0 | 1.23 |
| R156010010 | 032 | 1200 | 4100.0 | 750.0 | 1.13 |
Common to all listed parts
| Note: maximum permissible speed vmax | Force or torque and speed can be limited by the motor. |
| Weight [kg] | 0 |
