Shaft support blocks Parts
























Compare Shaft support blocks
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Weight [kg] | Dimension E [mm] | Dimension H [mm] | Dimension H1 (profiled rail systems) [mm] | Dimension N1 (profiled rail systems) [mm] |
|---|---|---|---|---|---|
| R105874000 | 0.48 | 66 | 42.0 | 76 | 38 |
| R105704000 | 0.89 | 82 | 50.0 | 88 | 44 |
| R105774000 | 0.86 | 82 | 50.0 | 88 | 44 |
| R105803000 | 0.21 | 49 | 34.0 | 60 | 29 |
| R105873000 | 0.21 | 49 | 34.0 | 60 | 29 |
| R105703000 | 0.49 | 64 | 40.0 | 70 | 34 |
| R105773000 | 0.48 | 64 | 40.0 | 70 | 34 |
| R105802500 | 0.18 | 44 | 31.0 | 54 | 26 |
| R105872500 | 0.18 | 44 | 31.0 | 54 | 26 |
| R105702500 | 0.37 | 56 | 35.0 | 61 | 30 |
| R105772500 | 0.37 | 56 | 35.0 | 61 | 30 |
| R105802000 | 0.11 | 39 | 25.0 | 45 | 22 |
| R105872000 | 0.11 | 39 | 25.0 | 45 | 22 |
| R105702000 | 0.18 | 42 | 30.0 | 51 | 25 |
| R105772000 | 0.18 | 42 | 30.0 | 51 | 25 |
| R105801600 | 0.07 | 32 | 22.0 | 38 | 18 |
| R105871600 | 0.07 | 32 | 22.0 | 38 | 18 |
| R105701600 | 0.11 | 38 | 25.0 | 42 | 21 |
| R105771600 | 0.11 | 38 | 25.0 | 42 | 21 |
| R105801200 | 0.05 | 27 | 19.0 | 33 | 16 |
| R105871200 | 0.05 | 27 | 19.0 | 33 | 16 |
| R105701200 | 0.07 | 30 | 20.0 | 35 | 16.5 |
| R105771200 | 0.13 | 30 | 20.0 | 35 | 16.5 |
| R105701000 | 0.06 | 27 | 18.0 | 31 | 14 |
Common to all listed parts
| Accessories for linear bushings | Shaft support blocks |
| Type | Shaft support block |
| Housing material | Aluminum = A |
