High precision ball guide rail BSHP Parts
Compare High precision ball guide rail BSHP
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal size [mm] | Format | Material (profiled rail systems) | Accuracy class | Number of sections |
|---|---|---|---|---|---|
| R164510341 | 15 | SNS - Standard guide rail | Hard chrome plated | H - Highly accurate | 1-piece |
| R164510331 | 15 | SNS - Standard guide rail | Hard chrome plated | H - Highly accurate | 1-piece |
| R167750238 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 8-piece |
| R167750237 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 7-piece |
| R167750236 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 6-piece |
| R167750235 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 5-piece |
| R167750234 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 4-piece |
| R167750233 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 3-piece |
| R167750232 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 2-piece |
| R167750231 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 1-piece |
| R167550238 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 8-piece |
| R167550237 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 7-piece |
| R167550236 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 6-piece |
| R167550235 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 5-piece |
| R167550234 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 4-piece |
| R167550233 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 3-piece |
| R167550232 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 2-piece |
| R167550231 | 20/40 | BNS - wide guide rail | Carbon steel | P - Precise | 1-piece |
| R167750438 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 8-piece |
| R167750437 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 7-piece |
| R167750436 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 6-piece |
| R167750435 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 5-piece |
| R167750434 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 4-piece |
| R167750433 | 20/40 | BNS - wide guide rail | Carbon steel | N - Normal | 3-piece |
Common to all listed parts
| Version | Ball rail system |
| Max. length Lmax [mm] | 3836.0 |
| Number of holes nB (profiled rail systems) | 64 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Weight [kg] | 0 |
| Recommended rail length (formula) | L = n<sub>B </sub>• T<sub> </sub>‒ 4 mm |
| Pitch T guide rail [mm] | 60 |
| Dimension T [mm] | 60 |
