High-precision ball runner block BSHP Parts
Compare High-precision ball runner block BSHP
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Width of runner block [mm] | Weight [kg] | Dimension A (profiled rail systems) [mm] | Dimension A1 (profiled rail systems) [mm] | Dimension A3 (profiled rail systems) [mm] |
|---|---|---|---|---|---|
| R166121420 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166121321 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166121320 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166129421 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166129420 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166129321 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166129320 | 70.0 | 0.5 | 70 | 35 | 23.5 |
| R166281421 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166281420 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166281321 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166281320 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166289421 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166289420 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166289321 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166289320 | 44.0 | 0.25 | 44 | 22 | 12 |
| R166181421 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166181420 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166181321 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166181320 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166189421 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166189420 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166189321 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166189320 | 63.0 | 0.3 | 63 | 31.5 | 21.5 |
| R166211421 | 34.0 | 0.1 | 34 | 17 | 9.5 |
Common to all listed parts
| Version | Ball rail system |
| Model | Super ball runner block |
| Material (profiled rail systems) | Carbon steel |
| Ball chain | Without ball chain (standard) |
| Self-aligning for compensation of misalignments | With self-alignment |
| Lubrication | Pre-lubricated, preserved |
| Maximum acceleration rate amax [m/s²] | 500.0 |
| Maximum permissible linear speed vmax [m/s] | 5.0 |
