KR AGILUS Parts
Browse Subcategories
Compare KR AGILUS
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Maximum payload | Rated payload | Maximum reach | Mounting position | Pose repeatability (ISO 9283) |
|---|---|---|---|---|---|
| 205456 | 6 kg | 3 kg | 901.5 mm | Floor | 0.03 mm |
| 210381 | 10 kg | 5 kg | 901.5 mm | Floor | 0.03 mm |
| 210493 | 6 kg | 3 kg | 706.7 mm | Floor | 0.03 mm |
| 215578 | 6 kg | 3 kg | 706.7 mm | Ceiling | 0.03 mm |
| 210495 | 10 kg | 5 kg | 1101 mm | Floor | 0.03 mm |
| 215579 | 10 kg | 5 kg | 1101 mm | Ceiling | 0.03 mm |
| 210361 | 6 kg | 3 kg | 706.7 mm | Floor | 0.03 mm |
| 210360 | 10 kg | 5 kg | 1101 mm | Floor | 0.03 mm |
| 215571 | 6 kg | 3 kg | 706.7 mm | Ceiling | 0.03 mm |
| 215574 | 6 kg | 3 kg | 706.7 mm | Wall | 0.03 mm |
| 211936 | 6 kg | 3 kg | 901.5 mm | Wall | 0.03 mm |
| 215576 | 10 kg | 5 kg | 1101 mm | Wall | 0.03 mm |
| 235180 | 10 kg | 5 kg | 1101 mm | Floor | 0.03 mm |
| 235184 | 6 kg | 3 kg | 706.7 mm | Ceiling | 0.03 mm |
| 234225 | 6 kg | 3 kg | 901.5 mm | Ceiling | 0.03 mm |
| 217651 | 10 kg | 5 kg | 901.5 mm | Ceiling | 0.03 mm |
| 235181 | 10 kg | 5 kg | 1101 mm | Wall | 0.05 mm |
| 235186 | 6 kg | 3 kg | 706.7 mm | Wall | 0.03 mm |
| 234226 | 6 kg | 3 kg | 901.5 mm | Wall | 0.03 mm |
| 235182 | 10 kg | 5 kg | 1101 mm | Ceiling | 0.03 mm |
| 236915 | 10 kg | 5 kg | 901.5 mm | Floor | 0.03 mm |
| 235300 | 10 kg | 5 kg | 1101 mm | Floor | 0.03 mm |
| 237703 | 10 kg | 5 kg | 901.5 mm | Ceiling | 0.03 mm |
| 237728 | 10 kg | 5 kg | 1101 mm | Ceiling | 0.03 mm |
Common to all listed parts
| Ambient temperature during operation | 5 °C to 45 °C (278 K to 318 K) |
| Ambient temperature during stor./transp. | -40 °C to 60 °C (233 K to 333 K) |
