Hydraulic steering units Parts

Showing 73–96 of 1,454 parts
Danfoss 253-3087-004 – ORB 25, ABW86A671FA21008LEAGA3A0AA10D
Danfoss
253-3087-004

ORB 25, ABW86A671FA21008LEAGA3A0AA10D

Danfoss 253-3080-004 – Series 25 787 LS Steering Unit
Danfoss
253-3080-004

Series 25 787 LS Steering Unit

Danfoss 253-3073-004 – Series 25 1230 LS Steering Unit, ABW86A711FD21006FEAGA3A1AA10D
Danfoss
253-3073-004

Series 25 1230 LS Steering Unit, ABW86A711FD21006FEAGA3A1AA10D

Danfoss 253-3071-004 – Series 25 1230 LS Steering Unit
Danfoss
253-3071-004

Series 25 1230 LS Steering Unit

Danfoss 253-3064-004 – Series 25 1230 LS Steering Unit
Danfoss
253-3064-004

Series 25 1230 LS Steering Unit

Danfoss 253-3045-004 – Series 25 623 LS Steering Unit
Danfoss
253-3045-004

Series 25 623 LS Steering Unit

Danfoss 253-3043-004 – S-25 SCU, ABW86A711FD210070EAGA3A1AA10D
Danfoss
253-3043-004

S-25 SCU, ABW86A711FD210070EAGA3A1AA10D

Danfoss 253-3038-004 – S-25 SCU, ABW86A691FD210070EAGA3A1AA10D
Danfoss
253-3038-004

S-25 SCU, ABW86A691FD210070EAGA3A1AA10D

Danfoss 253-3016-004 – Series 25 983 LS Steering Unit, ABW86A691FD020000EAGA3A1AA10D
Danfoss
253-3016-004

Series 25 983 LS Steering Unit, ABW86A691FD020000EAGA3A1AA10D

Danfoss 253-1051-004 – ORB 25, ABW76A710FA21008LEAGA3A1AA10D
Danfoss
253-1051-004

ORB 25, ABW76A710FA21008LEAGA3A1AA10D

Danfoss 253-1046-004 – Series 25 983 LS Steering Unit
Danfoss
253-1046-004

Series 25 983 LS Steering Unit

Danfoss 253-1045-004 – Series 25 983 LS Steering Unit
Danfoss
253-1045-004

Series 25 983 LS Steering Unit

Danfoss 253-1044-004 – ORB 25, ABW76A690FA020000EAGN3A1AA10D
Danfoss
253-1044-004

ORB 25, ABW76A690FA020000EAGN3A1AA10D

Danfoss 253-1042-004 – Series 25 983 LS Steering Unit
Danfoss
253-1042-004

Series 25 983 LS Steering Unit

Danfoss 253-1038-004 – ORB 25, ABW76A670FA020000EAGA3A1AA10D
Danfoss
253-1038-004

ORB 25, ABW76A670FA020000EAGA3A1AA10D

Danfoss 253-1025-004 – Series 25 983 LS Steering Unit
Danfoss
253-1025-004

Series 25 983 LS Steering Unit

Danfoss 253-1005-004 – Series 25 1230 LS Steering Unit
Danfoss
253-1005-004

Series 25 1230 LS Steering Unit

Danfoss 253-1004-004 – Series 25 983 LS Steering Unit
Danfoss
253-1004-004

Series 25 983 LS Steering Unit

Danfoss 253-1003-004 – Series 25 787 LS Steering Unit
Danfoss
253-1003-004

Series 25 787 LS Steering Unit

Danfoss 253-1002-004 – S-25 SCU, ABW76A650FA000000EAGA3A0AA10D
Danfoss
253-1002-004

S-25 SCU, ABW76A650FA000000EAGA3A0AA10D

Danfoss 253-1001-004 – S-25 SCU, ABW76A620FA000000EAGA3A0AA10D
Danfoss
253-1001-004

S-25 SCU, ABW76A620FA000000EAGA3A0AA10D

Danfoss 252-1021-004 – Series 25 787 CN Steering Unit
Danfoss
252-1021-004

Series 25 787 CN Steering Unit

Danfoss 252-1020-004 – Series 25 787 CN Steering Unit
Danfoss
252-1020-004

Series 25 787 CN Steering Unit

Danfoss 252-1019-004 – Series 25 492 CN Steering Unit
Danfoss
252-1019-004

Series 25 492 CN Steering Unit

Compare Hydraulic steering units

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNCylinder relief valve settingDisplacementFlow amplificationLoad circuitModel Code 1
253-3087-004276 bar [4000] PSI787 cm3/r [48.0 in3/r]1.60:1.00NON REACTIONABW86A671FA21008LEAGA3A0AA10D
253-3073-004207 bar [3000] PSI1230 cm3/r [75.0 in3/r]1.60:1.00NON REACTION, CYLINDER DAMPED, LEVEL 2ABW86A711FD21006FEAGA3A1AA10D
253-3043-004224 bar [3250] PSI1230 cm3/r [75.0 in3/r]1.60:1.00NON REACTION, CYLINDER DAMPED, LEVEL 2ABW86A711FD210070EAGA3A1AA10D
253-3038-004224 bar [3250] PSI983 cm3/r [60.0 in3/r]1.60:1.00NON REACTION, CYLINDER DAMPED, LEVEL 2ABW86A691FD210070EAGA3A1AA10D
253-3016-004None983 cm3/r [60.0 in3/r]1.60:1.00NON REACTION, CYLINDER DAMPED, LEVEL 2ABW86A691FD020000EAGA3A1AA10D
253-1051-004276 bar [4000] PSI1230 cm3/r [75.0 in3/r]NONENON REACTIONABW76A710FA21008LEAGA3A1AA10D
253-1044-004None983 cm3/r [60.0 in3/r]NONENON REACTIONABW76A690FA020000EAGN3A1AA10D
253-1038-004None787 cm3/r [48.0 in3/r]NONENON REACTIONABW76A670FA020000EAGA3A1AA10D
253-1002-004None623 cm3/r [38.0 in3/r]NONENON REACTIONABW76A650FA000000EAGA3A0AA10D
253-1001-004None492 cm3/r [30.0 in3/r]NONENON REACTIONABW76A620FA000000EAGA3A0AA10D

Common to all listed parts

Design code5
Fluid typeREFERENCE Danfoss TECHNICAL BULLETIN 3-401
IdentificationDANFOSS NUMBER ON NAMEPLATE
Inlet or LS relief settingNone
Inlet pressure rating241 bar [3500 lbf/in2]-DUCTILE HOUSING HIGH Pressure
Input torqueStandard
Neutral circuitLOAD SENSING, DYNAMIC SIGNAL
P,t,l, and r port size4X 1.0625-12 UN-2B SAE O-RING PORT
