GearMe modular two stage Parts
Compare GearMe modular two stage
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | B_1 STAGE DISPL GR1+1 | C_2 STAGE DISPL GR1+1 | I_IN BODY 1 STAGE GR1+1 | J_OUT 1 STAGE GR1+1 | L_IN BODY 2 STAGE GR1+1 |
|---|---|---|---|---|---|
| 181.20.020.00 | — | — | — | — | — |
| 181.20.018.00 | — | — | — | — | — |
| 181.20.016.00 | — | — | — | — | — |
| 181.20.015.00 | — | — | — | — | — |
| 181.20.013.00 | — | — | — | — | — |
| 181.20.009.00 | — | — | — | — | — |
| 181.20.008.00 | — | — | — | — | — |
| 181.12.001.00 | Displacement 4,3 cc | Displacement 1,2 cc | 3/4-16UNF | 9/16-18UNF | 3/4-16UNF |
| 181.10.098.00 | Displacement 7,8 cc | Displacement 2,6 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.080.00 | Displacement 4,3 cc | Displacement 4,3 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.071.00 | Displacement 4,3 cc | Displacement 1,2 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.070.00 | Displacement 2,2 cc | Displacement 1,2 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.069.00 | Displacement 4,3 cc | Displacement 1,7 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.067.00 | Displacement 6,0 cc | Displacement 4,3 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.064.00 | Displacement 4,3 cc | Displacement 3,8 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.062.00 | Displacement 1,2 cc | Displacement 1,2 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.059.00 | Displacement 7,8 cc | Displacement 3,8 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.055.00 | Displacement 4,3 cc | Displacement 1,7 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.054.00 | Displacement 4,3 cc | Displacement 2,6 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.051.00 | Displacement 7,8 cc | Displacement 7,8 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.044.00 | Displacement 3,8 cc | Displacement 1,7 cc | 3/8 GAS | 3/8 GAS | 3/8 GAS |
| 181.10.042.00 | Displacement 3,8 cc | Displacement 3,8 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.014.00 | Displacement 1,2 cc | Displacement 1,2 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
| 181.10.011.00 | Displacement 1,2 cc | Displacement 1,2 cc | 12x26xM5 | 12x26xM5 | 12x26xM5 |
Common to all listed parts
| O-Ring, Inside Diameter | Slash |
| OC DELIMITER (-) | - |
| Proposition 65 | Cancer and Reproductive Harm |
| Slash separator | Slash |
