Wago 765-2101/100-000
4-Channel Analog Input Voltage/Current + 4P IOL-A; Profinet; DC 24 V / 2.0 A; 8xM12 connection; WideLine
- MPN
- 765-2101/100-000
- Category
- I/O Systems
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Wago 765-2101/100-000?
Application area:
Decentralized processing of analog, digital and IO-Link signals
This device records analog current and voltage signals and records and controls IO-Link-capable digital field devices, e.g., sensors, actuators and hubs, that are received or controlled by a higher-level controller.
In addition, the device offers four IO-Link ports or 8 digital inputs/outputs designed as Class A Master.
Analog inputs:
The device has four electrically isolated analog channels for differential current and voltage signal acquisition from the field areas
0 ... 20 mA; 4 ... 20 mA; ±20 mA; 3.6 ... 21 mA NE43; 0 ... 10 V; ±10 V
IO-Link:
The device has several IO-Link communication interfaces for collaboration with IO-Link devices.
The IO-Link interface allows direct access to the process and diagnostic data and allows you to set the parameters of the connected devices during operation.
The IODD can also be downloaded via IODDfinder https://ioddfinder.io-link.com .
Specifications
Technical data - Fieldbus
| Communications | PROFINET, PROFINET IO device; 2-port switch, LLDP, MRP, SNMP |
| Connection technology: communication/fieldbus | 2 x D-coded M12; 4-pole |
| Interface standard | 10BASE-T/100BASE-TX; potential-free |
| Autonegotiation; autocrossover | Yes |
| PROFINET IO features | PROFINET IO device; 2-port switch, LLDP, MRP, SNMP |
Technical data - Device functions
| Parameter | Input filter, Input filter: 50 Hz / 60 Hz / Filter disabled, Output current, Temperature |
| Diagnostics | Undervoltage; overcurrent; overload; overtemperature |
| Device functions | Bluetooth®, OPC UA server |
| Visualization | Android/iOS app, Web server |
Technical data - Analog inputs
| Number of analog inputs | 4 |
| Signal type | Voltages and currents, Currents and Voltages |
| Signal characteristics | Differential |
| Measurement range | Currents: 0 … 20 mA; 4 … 20 mA; ±20 mA;Namur: 3,6 … 21 mA NE43;Volages: 0 … 10 V; ±10 V |
| Sensor connection | 4 x (2-wire, 3-wire, 4-wire); Shielded |
| Internal resistance | AI [I] 100 kΩ |
| Conversion time | ≤ 2,5 ms for each channel (Filter disabled) |
| Conversion method | Sigma Delta |
| Resolution (over entire range) | 16 Bit (15 bits + sign) |
| Measurement error (25 °C) | ≤ ± 0.1 % full scale value |
| Temperature coefficient | ≤ ± 0,01 %/K vom Messbereichsendwert |
| Interference frequency suppression | 50 Hz / 60 Hz / Filter disabled |
| Connection requirement (permissible cable type) | Shielded |
| Connection requirement (permissible cable length) | 30 m |
| Advanced diagnostics | Measurement range underflow/overflow; overflow/underflow in operating modes 0 … 20 mA, 4 … 20 mA, ± 20 mA, 3.6 … 21 mA NE43 |
| Isolation | Functional insulation: 2000 VDC system/channel; 800 VDC channel/channel |
Technical data - IO-Link master
| IO-Link master classification | Class A; V1.1 specification |
| Port-Modus | IO-Link: autoconfig, manual, tool-based, DI, DO |
| Cycle time | 400 μs (min.) |
| Operating mode | IO-Link master, DI or DO (adjustable for pin 4 per port); DI or DO (adjustable for pin 2 per port) |
Technical data - Supply (module)
| Connection technology: supply | 2 x L-coded M12; 5-pole |
| Supply voltage | 24 VDC (18 … 31.2 V); 1L; (2L looped through) |
| Current consumption (max.) | 16000 mA |
| Current consumption (note) | per supply line; overload- and short-circuit-protected; 12 A at 70 °C; Analog Port Current comsuption (max): 4 x 0.5 A |
| Reverse voltage protection | Yes |
Technical data - IO-Link ports
| Number of digital inputs | 8 |
| Number of digital outputs | 8 |
| Signal type (voltage) | 24 VDC |
| Input characteristic | high-side switching |
| Input filter | 0.2 … 20 ms |
| Input characteristic | Type 3, per IEC 61131-2 |
| Output current (per channel) | 2 A (typ.) for DO |
| Supply current per port | 1L: 1 A for IO-Link; 4 A (max.) for DIO |
Technical data - Connection data
| Connection technology: I/O | 4 x A-coded M12; 5-pole (IO-Link port); 4 x A-coded M12; 5-pole (Analog input) |
Physical data
| Width | 60 mm / 2.362 inches |
| Height | 30 mm / 1.181 inches |
| Depth | 210 mm / 8268 inches |
Material data
| Weight | 576 g |
| Conformity marking | CE |
Environmental requirements
| Ambient temperature (operation) | -25 … +70 °C |
| Ambient temperature (storage) | -40 … +80 °C |
| Protection type | IP67 |
| Protection class | III |
| Pollution degree | 3 (EN 60664-1) |
| Operating altitude | 0 … 2000 m / 0 … 6562 ft |
| Relative humidity (without condensation) | 95 % |
| Vibration resistance | 5g per IEC 60068-2-6 |
| Shock resistance | Short-term: 50g/11 ms/half-sine per IEC 60068-2-27; Long-term: 30g/6 ms/half-sine per IEC 60068-2-29 |
| EMC immunity to interference | per EN 61000-6-2 |
| EMC emission of interference | per EN 61000-6-4 |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | Box |
| Country of origin | DE |
| GTIN | 4066966730647 |
| Customs tariff number | 85389099990 |
Product Classification
| UNSPSC | 32151705 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
