Wago 762-5205/8000-001
Touch Panel 600; 39.6 cm (15,6"); 1920 x 1080 pixels; 2 x ETHERNET, 2 x USB, Audio; Visu Panel
- MPN
- 762-5205/8000-001
- Category
- Touch Panels
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Wago 762-5205/8000-001?
PIO2 hardware configuration
2 x ETHERNET port for connecting to field devices and the engineering tool
2 x USB port for optional connection of a USB stick, mouse or keyboard
Audio interface for connecting a headphone or loudspeaker
Specifications
Technical data
| Display diagonal | 39.6 cm (15.6 inches) |
| Display | Multitouch glass front; Capacitive touchscreen with a glass surface |
| Display colors | 16.7 million colors |
| Graphics resolution | (1920 x 1080) px |
| Contrast ratio | 800:1 |
| Viewing angle (horizontal/vertical) | 85° / 85° |
| Brightness | 500 cd/m<sup>2</sup> |
| Visualization | Web server |
| ETHERNET protocols | DHCP, DNS, FTP, FTPS, HTTP, HTTPS, SSH |
| Communications | Web browser, Web browser (HTML5), Modbus TCP master/slave, Modbus (UDP), WagoAppPlcModbus Library, ETHERNET, EtherNet/IPTM Adapter (slave), EtherNet/IPTM Scanner, EtherCAT® Master, OPC UA Server/Client, OPC UA Pub/Sub (can be installed later), MQTT, Telecontrol protocols, requires an additional license, MicroBrowser (including visualization of CODESYS V2.3), requires an additional license, EtherNet/IPTM Adapter (slave), library for e!RUNTIME (prerequisite: e!RUNTIME PLC 600 license), Modbus TCP Master/Slave (prerequisite: e!RUNTIME PLC 600 license), EtherCAT Master, requires an additional license (prerequisite: e!RUNTIME PLC 600 license), BACnet/IP, requires an additional license (e!RUNTIME PLC 600 license is required) |
| Operating system | Real-time Linux (with PREEMPT_RT patch) |
| Processor | ARM® Cortex® A9 Quad-Core 1.0 GHz |
| Programming environment | CODESYS V3.5, Firmware Release 24 or higher, e!COCKPIT (based on CODESYS V3) up to Firmware Release 22, e!COCKPIT (based on CODESYS V3) |
| Main memory (RAM) | 2,048 MB |
| Internal memory (flash) | 4096 MB |
| Program memory | 32 MB |
| Data memory | 128 MB |
| Type of memory card | microSD (max. 2 GB); microSDHC (max. 32 GB) |
| Indicators | Three-color LED (red, green, blue) |
| Control Elements | capacitive (glass), 2 capacitive keys, proximity sensor |
| Supply voltage | 24 VDC, SELV (18 … 31.2 V); with reverse voltage protection |
| Operating power | 10.3 W, without USB load; 15.8 W, with USB load |
Connection data
| Connection technology: communication/fieldbus | Modbus (TCP): 2 x RJ-45; 2 x USB 2.0 host (type A) |
| Connection technology: supply | 1 x Included female connector (734-103/037-000) with three CAGE CLAMP® connections |
Physical data
| Width | 420 mm / 16.535 inches |
| Height | 283 mm / 11.142 inches |
| Depth | 58 mm / 2.283 inches |
| Panel cutout (W x H) | (406 x 268) mm |
Mechanical data
| Mounting type | Clamping elements (included) |
Material data
| Weight | 3250 g |
Environmental requirements
| Ambient temperature (operation) | -20 … +55 °C (Vertical mounting position; -20 … +50 °C, other mounting positions) |
| Ambient temperature (storage) | -20 … +70 °C |
| Protection type | IP65 |
| Note on protection type | IP65 (front side); IP20 (rear side), per EN 60529 |
| Relative humidity (without condensation) | 90 % |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | Box |
| Country of origin | DE |
| GTIN | 4066966056334 |
| Customs tariff number | 84714100000 |
Product Classification
| UNSPSC | 43211903 |
| ETIM 9.0 | EC001414 |
| ETIM 10.0 | EC001414 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
