Home / Wago / PCB Terminal Blocks and Pluggable Connectors / Wago 2626-1358
Wago

Wago 2626-1358

PCB terminal block; 6 mm²; Pin spacing 12.5 mm; 8-pole; Push-in CAGE CLAMP®; 6,00 mm²; gray

MPN
2626-1358
Price and lead time confirmed within 1 business day
Request a Quote

A real person replies, typically within 1 business day — see our privacy policy.

What happens next
  1. We check stock, condition and lead time
  2. You get a written quote by email
  3. Approve it and we ship — in-stock parts within 1 business day
  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • Ships via
  • 100% positive eBay feedback

Have spare Wago parts? We buy surplus →

What is the Wago 2626-1358?

PCB terminal block, 2626 Series, solder pin dimensions 1.5 x 1 mm

This PCB terminal block (item number 2626-1358) is designed to connect conductors quickly and easily. It offers the flexibility needed for different mounting types. Conductors can only be connected to this PCB terminal block if their strip length is between 13 and 15 mm . Featuring one conductor terminal along with Push-in CAGE CLAMP®, this product outperforms the competition. Our Push-in CAGE CLAMP® is a universal, maintenance-free connection solution for all conductor types, featuring a winning design: both solid and fine-stranded conductors with ferrules can be directly inserted without the need for tools or any preparation, such as crimping the ferrule. Dimensions: (96.8 x 23.6 x 24.2) mm (width x height x depth). Depending on the conductor type, this PCB terminal block is ideal for conductor cross sections ranging from 0.2 mm² to 10 mm².

The contact surface is coated with tin. This PCB terminal block is operated with an operating tool. The PCB terminal block is designed for THT soldering. The conductor is designed to be inserted into the board at a 0° angle..

Specifications

Notes

Variants:Other pole numbers, Direct marking, Other colors, Other versions (or variants) can be requested from WAGO Sales or configured at https://configurator.wago.com/.

Electrical data - Ratings per IEC/EN

Ratings perIEC/EN 60664-1
Nominal voltage (III/3)1000 V
Rated impulse withstand voltage (III / 3)8 kV
Rated voltage (III/2)1000 V
Rated impulse withstand voltage (III/2)8 kV
Nominal voltage (II/2)1000 V
Rated impulse withstand voltage (II/2)8 kV
Rated current48 A
Ratings perIEC/EN 60664-1 / IEC/EN 60664-1 / IEC/EN 60664-1
Overvoltage categoryIII / III / II
Pollution degree3 / 2 / 2
Nominal voltage1000 V / 1000 V / 1000 V
Rated impulse withstand voltage8 kV / 8 kV / 8 kV
Rated current48 A / 48 A / 48 A

Electrical data - Ratings per UL

Rated voltage UL (Use Group B)600 V
Rated current UL (Use Group B)38 A
Rated voltage UL (Use Group C)600 V
Rated current UL (Use Group C)38 A

Electrical data - Ratings per CSA

Approvals perCSA
Rated voltage CSA (Use Group B)600 V
Rated current CSA (Use Group B)38 A
Rated voltage CSA (Use Group C)600 V
Rated current CSA (Use Group C)38 A
Approvals perCSA / CSA / CSA
Use groupB / C / D
Rated voltage600 V / 600 V
Rated current38 A / 38 A

Connection data

Clamping units8
Total number of potentials8
Number of connection types1
Number of levels1

Connection data - Connection 1

Connection technologyPush-in CAGE CLAMP®
Actuation typeOperating tool
Solid conductor0.2 … 10 mm² / 24 … 8 AWG
Fine-stranded conductor0.2 … 10 mm² / 24 … 8 AWG
Fine-stranded conductor; with insulated ferrule0.25 … 6 mm²
Fine-stranded conductor; with uninsulated ferrule0.25 … 6 mm²
Fine-stranded conductor; with twin ferrule0.25 … 2.5 mm²
Strip length13 … 15 mm / 0.51 … 0.59 inches
Conductor connection direction to PCB0 °
Pole number8

Physical data

Pin spacing12.5 mm / 0.492 inches
Width96.8 mm / 3.811 inches
Height23.6 mm / 0.929 inches
Height from the surface19.6 mm / 0.772 inches
Depth24.2 mm / 0.953 inches
Solder pin length4 mm
Solder pin dimensions1.5 x 1 mm
Drilled hole diameter with tolerance2 (+0.1) mm

Mechanical data

Mounting typeFeed-through mounting

PCB contact

PCB contactTHT
Solder pin arrangementover the entire terminal strip (in-line)
Number of solder pins per potential2

Material data

Note (material data)Information on material specifications can be found here
Colorgray
Material groupI
Insulation material (main housing)Polyamide (PA66)
Flammability class per UL94V0
Clamping spring materialChrome-nickel spring steel (CrNi)
Contact materialElectrolytic copper (ECu)
Contact platingTin
Fire load0.341 MJ
Weight42.9 g

Environmental requirements

Limit temperature range-60 … +105 °C
Processing temperature-35 … +60 °C
Continuous operating temperature-60 … +105 °C

Commercial data

PU (SPU)16 pcs
Packaging typebox
Country of originPL
GTIN4066966506167
Customs tariff number85369010000

Product Classification

UNSPSC39121409
ETIM 9.0EC002643
ETIM 10.0EC002643
ECCNNO US CLASSIFICATION

Environmental Product Compliance

RoHS Compliance StatusCompliant,No Exemption
