Wago
206-2151VDE combination screwdriver; Crosshead and slot +/- PZ1/S; VDE tested; 1000 V; insulated; 2-component grip; size 2 (110 mm); green/gray
Wago 206-2166
VDE Torx® screwdriver; T20; VDE tested; 1000 V; insulated; 2-component grip; size 2 (110 mm); green/gray
- MPN
- 206-2166
- Category
- Tools
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Wago 206-2166?
VDE Torx® screwdriver; T20; VDE tested; 1000 V; insulated; 2-component grip; size 2 (110 mm); green/gray 206-2166
Specifications
Notes
| Safety Information | Always use the appropriate VDE screwdriver variant for your screw head variant to prevent injury from slipping and damage to the VDE screwdriver or screw head.Keep the VDE screwdriver free from oil, grease and moisture to prevent slipping and potential injury.If the tip is damaged, replace the VDE screwdriver to prevent slipping and injury.Do not use the VDE screwdriver if the handle or insulation is damaged to prevent the risk of electric shock.Do not use the VDE screwdriver to open the contact spring on products with operating slots.Do not use the VDE screwdriver as a prying tool or chisel.Wear approved eye protection and the necessary personal protective equipment for your application.Environmental and storage information: Ensure that VDE screwdrivers are not exposed to strong heat sources (e.g., heating pipes or steam lines) or to UV radiation. |
| Safety information 2 | 1. Work on live or load-carrying parts may only be performed by properly trained and qualified personnel.2. Use only for its intended purpose!3. Observe national regulations, standards and guidelines!4. Follow the technical specifications of the products!5. Do not use soiled components.!6. Use only compatible bits and drives! |
Physical data
| Width | 27 mm / 1.063 inches |
| Height | 25 mm / 0.984 inches |
| Depth | 190 mm / 7.48 inches |
| Blade length | 80 mm |
| Grip length | 110 mm |
Mechanical data
| Tip type | T20 |
| Continuous blade | No |
| Blade type | Straight |
| Roll-away protection | Yes |
| Hanging eyelet | Yes |
| Grip marking | Yes |
| Head marking | Yes |
Material data
| Color | green/gray |
| Material 1 | Polypropylen (PP) |
| Material 2 | Thermoplastische Elastomere (TPE) |
| Blade material | 61CrSiV5 |
| Blade surface | Burnished |
| Weight | 52 g |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | unpacked |
| Country of origin | DE |
| GTIN | 4066966470819 |
| Customs tariff number | 82054000000 |
Product Classification
| UNSPSC | 27111701 |
| ETIM 9.0 | EC000801 |
| ETIM 10.0 | EC000801 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
206-2166: frequently asked questions
When can 206-2166 be shipped?
206-2166 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 206-2166 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 206-2166 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 206-2166, subject to availability and destination.
