Siemens 8LK4003-1AA53

Copper position change L1-L3, 80 x 10 mm, direction: 600 to 400 mm, installation: right

MPN: 8LK4003-1AA53
Category: Mounting depth adapter

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 8LK4003-1AA53?

copper position change L1-L3, 80 x 10 mm, direction: 600 to 400 mm, installation: right

Specifications

Model

product brand name	ALPHA 3200 Eco
type of busbar profile	bare

General technical data

number of poles	1
short-circuit current rating	65 kA
position of main busbar	Rear

Main circuit

operational current rated value

1 810 A

Mechanical Design

height	80 mm
width	100 mm
width of the busbar	80 mm
depth	10 mm
mounting height	80 mm
installation location	main busbar
thickness of the busbar	10 mm
busbar center-to-center spacing	185 mm
Net Weight	2.283 kg
