What is the Siemens 8GK2348-7KL01?

ALPHA 630 UNIVERSAL, Floor-mounted cabinet, with distribution board panel, IP55, Protection class 1, H: 1800 mm, W: 600 mm, T: 250 mm, RAL 7035, with door with inspection window

Specifications

Model

product brand name	ALPHA
product designation	Free-standing cabinet
design of the product	With distribution board panel
surface processing	powder-coated

Protection class

protection class IP	IP55
operating resource protection class	Safety class 1
IK protection class	IK09
suitability for interaction lightning protection	Yes
suitability for use for outside use	No

Appearance

RAL color number	7 035
product component — cable entry	Yes
product component — mounting plate	No
special product feature	With door with inspection window
product extension optional side-by-side mounting	Yes

Mechanical Design

height	1 800 mm
width	600 mm
depth	250 mm
installation depth	250 mm
fastening method	floor mounting
Net Weight	68.75 kg
material of the enclosure	Steel
