Siemens 7KE9202-0DA10-3BC0

SICAM PQ Analyzer V3 download, software, documentation and license(s) for download

MPN: 7KE9202-0DA10-3BC0

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Siemens parts? We buy surplus →

What is the Siemens 7KE9202-0DA10-3BC0?

SICAM PQ Analyzer V3 download, software, documentation and license(s) for download. Consignee e-mail address required for delivery. PQ Professional with Incident Explorer, PQ Explorer, Report Browser and PQ Inspector for PQ Index, status overview and manual report creation, use on separate archive computer supports up to 5 clients archive transfer from more than 5 servers/full servers operating system Windows 10 (64-bit), Windows Server 2019 (64-bit) target system SICAM PAS / PQS

Specifications

General technical data

target system	SICAM PQS
national language / of the software	German / English

Product details

product description

power quality analyzer software

Model

product designation	SICAM PQ Analyzer
product version	PQ Professional - up to 5 clients, archive transfer of more than 5 SICAM PAS/PQS full servers

Power Quality functions

power quality assessment function / incident explorer, event viewer, fault event viewer	Yes
power quality assessment function / PQ Explorer	Yes
power quality assessment function / PQ Explorer via Report Browser	Yes
power quality assessment function / PQ Inspector	Yes

Product Functions

user interface info texts can be translated into any national language	Yes
Unicode support for process data	Yes
diagnostics function	Yes
analysis function	Yes
project planning function	No
evaluation function	Yes
parameterizing function	No
querying/read-in of PQDIF files from hard disk	Yes
evaluation of fault records	Yes
fault location (with regard to fault records)	Yes

Display and operation

horizontal image resolution / of the graphics card	1 280 pixel
vertical image resolution / of the graphics card	1 024 pixel

Requirements

number of colors / of the graphics card	65 536
design of the drive/storage medium / required / DVD drive	No
operating system / usable / Windows 7	Yes
operating system / usable / Windows 10	Yes
operating system / usable / Windows 2012 Server	Yes
operating system / usable / Windows 2016 Server	Yes
operating system / usable / Windows Server 2019	Yes
processor clock frequency / minimum	2 GHz
viewer software / required	SIGRA for extended fault-record analysis as an option
storage capacity / on hard disk / required	100 Gbyte
storage capacity / of the main memory or RAM / minimum	16 Gbyte

Cybersecurity

type of access control / role-based access control (RBAC)	Yes
product function / firmware identifier	Yes
cybersecurity / secure communication	Yes
cybersecurity / data integrity	Yes
