Siemens 6MD9020-3MA10-8AA0
SICAM PAS Compact download, software, documentation and license(s) for download
- MPN
- 6MD9020-3MA10-8AA0
- Category
- Start-Up-Kits
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6MD9020-3MA10-8AA0?
SICAM PAS Compact download, software, documentation and license(s) for download. Specification of an email address (consignee) for delivery is absolutely required.
Specifications
General technical data
| target system | substation automation - IEDs (bay controller, protection device, ) |
| national language / of the software | German / English |
Product details
| product description | power automation system |
| product feature / connection of third-party devices | Yes |
Model
| product designation | SICAM PAS - base module |
Product Functions
| user interface info texts can be translated into any national language | Yes |
| Unicode support for process data | Yes |
| diagnostics function | Yes |
| communication function | Yes |
| project planning function | No |
| evaluation function | No |
| parameterizing function | Yes |
| automatic scanning and detection of PQ devices in the network | No |
| querying and storing of PQDIF files with IEC 61850 | No |
| querying/read-in of PQDIF files from hard disk | No |
| querying and storing of fault records via IEC 61850 | Yes |
| querying and storing of fault records via FTP | No |
| querying and storing of fault records via SIPROTEC 4 service interface | Yes |
| evaluation of fault records | Yes |
| fault location (with regard to fault records) | No |
| parameterization of PQ devices | No |
| automatic reading in of PQDIF files (from third-party devices) | No |
| storing of events in the archive | Yes |
| forwarding of operating data (messages, measured values) to HMI SICAM SCC, forwarding with SIMATIC WinCC | Yes |
| forwarding of operating data (messages, measured values) to control centers via telecontrol protocols | Yes |
| time synchronization for connected devices | Yes |
Display and operation
| horizontal image resolution / of the graphics card | 1 280 pixel |
| vertical image resolution / of the graphics card | 1 024 pixel |
Requirements
| number of colors / of the graphics card | 65 536 |
| design of the drive/storage medium / required / DVD drive | No |
| operating system / usable / Windows 7 | Yes |
| operating system / usable / Windows 10 | Yes |
| operating system / usable / Windows 2012 Server | Yes |
| operating system / usable / Windows 2016 Server | Yes |
| operating system / usable / Windows Server 2019 | Yes |
| processor clock frequency / minimum | 2 GHz |
| storage capacity / on hard disk / required | 100 Gbyte |
| storage capacity / of the main memory or RAM / minimum | 16 Gbyte |
Cybersecurity
| type of access control / role-based access control (RBAC) | Yes |
| product function / firmware identifier | Yes |
| cybersecurity / secure communication | Yes |
| cybersecurity / data integrity | Yes |
Time synchronization
| type of time synchronization | SNTP |
