Siemens 6GT2780-0DC20

SIMATIC RTLS Locating Manager initial position detection 1000 for 1,000 transponders

MPN: 6GT2780-0DC20

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Siemens parts? We buy surplus →

What is the Siemens 6GT2780-0DC20?

SIMATIC RTLS Locating Manager initial position detection 1000 for 1,000 transponders, option for license Basic, single license, software and license key download - - email address required for delivery .

Specifications

General

product brand name	SIMATIC RTLS
Technical Product Detail Page	https://i.siemens.com/1P6GT2780-0DC20
software version	V2.13.0.0

product functions

product version	add-on license for Locating Manager Basic 1000
product description	Initial position determination for all transponders after server restart
product options	Initial position determination after server restart for all tags which are currently located within locating ranges of the system / Configuration of time and performance behavior for the position determination / Option to manually start the position determination / in connection with the message management a message is generated which signals the final system availability
PROFINET conformity class	F
product function — web-based management	No
product function — MIB support	No
product function — TRAPs via email	No
product function — configuration with STEP 7	No
product function — PROFINET IO diagnosis	No
protocol / is supported — SSH	No
protocol / is supported — HTTP	No
protocol / is supported — HTTPS	No
protocol / is supported — NETCONF	No
protocol / is supported — DCP	No
protocol / is supported — LLDP	No
protocol / is supported — SNMP v1	No
protocol / is supported — SNMP v2	No
protocol / is supported — SNMP v2c	No
protocol / is supported — SNMP v3	No
protocol / is supported — IGMP (snooping/querier)	No
national language — of the software	German
national language — of the documentation / German	Yes
national language — of the documentation / English	Yes
national language — of the documentation / French	No
national language — of the documentation / Chinese (simplified)	Yes

software requirements / header

operating system — usable / Windows 10	Yes; clients
operating system — usable / Windows 7	No; nur für Clients
operating system — usable / Windows 2016 Server	Yes; server and clients
operating system — usable / Windows 2012 Server	No
operating system — usable / Windows 2008 Server	No; As of R2
operating system — usable / Windows Server 2019	Yes; server and clients
browser software / required	no

hardware requirements

processor clock frequency / minimum	2 Hz; GHz (dual core processor)
storage capacity — of the work memory / required / minimum	2000 Mibyte
storage capacity — on hard disk / required	2 Gibyte
storage capacity — on hard disk / recommended	100 Gibyte

further information / internet links

internet link — to web page: selection aid TIA Selection Tool	https://www.siemens.com/tstcloud
internet link — to web page: identification and localization systems	https://www.siemens.com/ident
internet link — to web page: SiePortal	https://sieportal.siemens.com/
internet link — to website: Image database	https://www.automation.siemens.com/bilddb
internet link — to website: CAx-Download-Manager	https://www.siemens.com/cax
internet link — to website: Industry Online Support	https://support.industry.siemens.com

security information

Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 6GT2780-0DC20PDF
